2021 Maverick - Lower Frame Assembly

2021 Maverick - Lower Frame Assembly

The 2021 Maverick Lower Frame Assembly provides structural integrity for your mower, supporting key components and ensuring smooth operation. If you're in need of replacement parts for the lower frame, BadBoyMowerParts.com has a full range of Bad Boy Mower Parts for your 2021 Maverick. Our Bad Boy Mower Part diagrams help you identify the right parts for repairs or upgrades to the lower frame assembly. With Bad Boy Lawn Mower Parts, you can be confident that your replacement parts are of the highest quality. Shopping for Bad Boy Parts Online is simple, and with Free Shipping On Orders Over $100, you’ll receive your parts quickly and at no extra charge, making maintenance hassle-free.

Bad Boy Mower Parts Lookup

2021 Maverick - Lower Frame Assembly
  Position Number SKU Product Title Price
9 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
13 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
19 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
40 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
44 018-0026-00 018-0026-00 - 1-14 X 5 1/2 BOLT GR 8
$13.90
45 018-0028-00 018-0028-00 - 3/8x2 1/2" Hex Bolt
$4.39
49 018-1055-00 018-1055-00 - 1/2 x 3/4 Bolt
$2.99
52 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
63 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
64 018-5044-00 018-5044-00 - 3/8 x 1 Carriage Bolt
$2.99
82 019-2073-00 019-2073-00 -.390 ID Plastic Washer
$2.99
88 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
107 026-0019-01 026-0019-01 - Foot Pedal Assembly (See Models Used On For Details)
$93.69
112 028-0002-00 028-0002-00 - Actuator Bar-Front (See Models Used On For Detail)
$78.08
113 028-0003-00 028-0003-00 - Actuator Bar-Rear (See Models Used On For Detail)
$78.08
116 028-0070-00 028-0070-00 - Neutral Rod
$12.48
120 029-7040-00 029-7040-00 - EZT Front Bumper (See Models Used On For Detail)
$31.17
123 030-7040-00 030-7040-00 - 1/4 x 1 Hex Head Tek Screw
$2.99
124 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F Thread Cutting Screw
$2.99
127 031-0510-00 031-0510-00 - Actuator Linkage (See Models Used On For Details)
$46.84
132 032-9002-00 032-9002-00 - Isolator - Red Dot
$70.97
141 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
155 039-5944-05 039-5944-05 - Pump Idler Bracket Assy-EZT
$70.97
166 044-2004-00 044-2004-00 - Bow Pin
$2.99
167 044-2008-00 044-2008-00 - Neutral Rod Clip
$2.99
178 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
199 070-5491-00 070-5491-00 - 2021 Maverick Frame--Painted
$1199.99
230 091-8002-00 091-8002-00 - Independently Articulating Front Susp. Arms Patent Decal
$5.49
237 250-2751-21 250-2751-21 - 2021 Maverick RH Arm Assembly - Short
$199.99
238 250-2801-21 250-2801-21 - 2021 and Newer Maverick LH Front Suspension Arm Assy
$132.68
239 250-2851-21 250-2851-21 - 2021 and Newer Maverick RH Long Front Suspension Arm Assy
$149.99
