2021 Rebel - Engine - Kohler CV752

2021 Rebel - Engine - Kohler CV752

For those with the 2021 Rebel Engine - Kohler CV752, BadBoyMowerParts.com provides the essential Bad Boy Mower Parts needed to keep your engine in excellent working condition. Whether you're looking for replacement parts like carburetors, filters, or fuel pumps, we have it all. Our Bad Boy Mower Part diagrams make it easy to identify and select the exact parts for your Kohler CV752 engine. Our high-quality Bad Boy Lawn Mower Parts are designed to provide reliable performance and durability. With Bad Boy Parts Online, ordering the right parts for your mower is straightforward, and you can enjoy Free Shipping On Orders Over $100, allowing you to save on shipping costs.

Bad Boy Mower Parts Lookup

2021 Rebel - Engine - Kohler CV752
  Position Number SKU Product Title Price
1A 063-2000-09 063-2000-09 - Kohler Command (Non-EFI Models)
$121.25
2A 055-8021-75 055-8021-75 - 52" Throttle Cable ONLY (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$28.88
2B 054-8017-00 054-8017-00 - 62" Choke Cable (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$25.80
5 013-0075-00 013-0075-00 - M8 - 1.25 Zinc Nut
$3.29
33 015-1013-00 015-1013-00 - 2019 - 2022 Rebel Kohler CV752 Muffler Catalytic Combustion # 582937-MUF1701 REV 3
$199.00
37 015-2751-00 015-2751-00 - Exhaust Gasket for 27,30 hp Kohler Engines
$6.56
39.2 015-8000-00 015-8000-00 - Spark Plug (RC12YC or Equivalent)
$13.90
39.3 063-5001-00 063-5001-00 - Kohler Fuel Filter
$19.25
39.4 063-5400-00 063-5400-00 - Oil Filter (Long) for Kohler Engines
$22.46
39.5 063-8019-00 063-8019-00 - Outer Air Filter, Fits all except 23 Briggs/Diesel
$35.84
39.6 063-8020-00 063-8020-00 - Inner Canister Air Filter - Fits All except 23 Briggs/Diesel
$32.65
49 018-0074-00 018-0074-00 - 7/16-20 x 2 3/4 Hex Bolt
$2.99
50 018-1075-00 018-1075-00 - 3/8 x 1 1/8 Engine Mounting Bolt
$2.99
79 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
82 019-6029-00 019-6029-00 - 1.140x1.750x.132 Flat Washer
$2.99
86 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
127 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley - Extended Shaft (See Models Used On For Details)
$42.58
136 041-8050-00 041-8050-00 - Pump Belt (See Models Used On For Detail)
$80.24
137 042-5020-00 042-5020-00 - 1/4 X 2 Square Key Stock
$2.99
148 051-5401-00 051-5401-00 - Kohler/Briggs Oil Drain Hose
$31.17
157 064-5301-01 064-5301-01 - 12" Red Battery Cable for Rebel/Rebel X
$12.94
167 070-1000-00 070-1000-00 - PTO Clutch (See Models Used On For Details)
$279.99
168 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
179 086-0005-00 086-0005-00 - Cable - Starter to Chassis (See Models Used On For Details)
$10.21
