2021 Rebel - Seat Detail

2021 Rebel - Seat Detail

The 2021 Rebel Seat Detail is an important part of your mower's comfort and functionality. BadBoyMowerParts.com offers a variety of Bad Boy Mower Parts to replace or upgrade the seat on your 2021 Rebel. Our Bad Boy Mower Part diagrams help you identify the seat components and ensure you find the right fit. We offer high-quality Bad Boy Lawn Mower Parts that provide long-lasting durability. Shopping for Bad Boy Parts Online is fast and convenient, and with Free Shipping On Orders Over $100, you’ll get your seat parts delivered to you at no extra charge.

Bad Boy Mower Parts Lookup

2021 Rebel - Seat Detail
  Position Number SKU Product Title Price
1D 071-5065-07 071-5065-07 - Seat Switch fits the 071-5065-00 (See Models Used On For Details)
$42.58
16 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
19 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
21 013-9005-00 013-9005-00 - 5/16-18 Nylock Jam Nut
$2.99
44 018-0024-00 018-0024-00 - M6-1.0 X 16MM HEX BOLT
$2.99
65 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
76 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
83 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
99 026-2019-00 026-2019-00 - Seat Plate 2019-2024 Rebel, Renegade & Rogue
$99.32
109 028-0090-00 028-0090-00 - Seat Latch Rod Assembly (See Models Used On For Detail)
$38.97
128 034-1025-00 034-1025-00 - Brake Spring (See Models Used On For Detail)
$12.48
160.0 067-0020-19 067-0020-19 - EPA Cannister Assembly Rebel/Renegade Gas/Rogue (See Models Used On For Details)
$47.62
160.1 067-0020-00 067-0020-00 - Carbon Canister
$62.40
160.2 072-8073-00 072-8073-00 - 3/16" Vinyl Hose Clamp
$2.99
160.3 072-8070-00 072-8070-00 - Tank Hose Clamp 3/16 (See Models Used On For Detail)
$2.99
160.4 051-2025-66 051-2025-66 - 66" 3/16 Vinyl EPA Line
$13.26
160.5 051-8072-38 051-8072-38 - 38" 1/4 Vinyl Tubing
$28.39
160.6 073-8068-00 073-8068-00 - Fuel Line T
$9.70
170.0 071-5060-18 071-5060-18 - 2019 - 2021 Rebel Seat w/ Seatbelt
$599.99
170.1 071-5015-00 071-5015-00 - Seat Rails
$93.69
170.2 071-5061-00 071-5061-00 - Pair of Armrest for the 071-5060-00 2016 - 2018 Outlaw, Outlaw/XP, 2019-2021 Rebel
$119.99
170.3 071-5063-00 071-5063-00 - Seat Cover for 071-5060-00 for the 2016 - 2018 Outlaw, Outlaw/XP, 2019-2021 Rebel
$134.99
170.4 071-5064-00 071-5064-00 - Back Cover for 071-5060-00 Used on 2016- 2018 Outlaw, Outlaw/XP, 2019 - 2021 Rebel
$160.49
170.5 071-8061-00 071-8061-00 - Seat Switch (See Models Used On For Detail)
$19.14
171.0 071-5065-00 071-5065-00 - 2019 - 2021 Seat with Seatbelt with ROPS (See Models Used On For Details)
$899.99
171.1 071-5065-02 071-5065-02 - Seatbelt for 2019-2021 Rebel & Renegade
$132.68
171.2 071-5065-03 071-5065-03 - Backrest Cushion fits the 071-5065-00 for 2019-2021 Rebel & Renegade
$180.99
171.3 071-5065-04 071-5065-04 - Seat Cushion fits the 071-5065-00 for 2019-2021 Rebel & Renegade
$191.99
171.4 071-5065-05 071-5065-05 - Seat Rail Kit fits the 071-5065-00 (See Models Used On For Details)
$85.17
171.5 071-5065-06 071-5065-06 - Armrest Kit fits the 071-5065-00 for 2019-2021 Rebel & Renegade
$139.99
