2021 Renegade - Gas - Deck Height Dial Detail

2021 Renegade - Gas - Deck Height Dial Detail

The 2021 Renegade - Gas Deck Height Dial Detail helps you precisely adjust the cutting height of your mower for a consistent and clean cut. At BadBoyMowerParts.com, we offer top-quality Bad Boy Mower Parts designed to maintain and improve this feature. Our Bad Boy Mower Part diagrams give you clear instructions on locating and installing deck height dial components for your 2021 Renegade - Gas. With the durability of our Bad Boy Lawn Mower Parts, you can rely on your mower to perform consistently. Ordering Bad Boy Parts Online is fast and easy, and with Free Shipping On Orders Over $100, you’ll receive your parts quickly and without any extra delivery charges.

Bad Boy Mower Parts Lookup

2021 Renegade - Gas - Deck Height Dial Detail
  Position Number SKU Product Title Price
8 013-0080-00 013-0080-00 -.630 ID x 1.130 OD x.062 THK F/W Nylon Black
$2.99
12 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
15 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
20 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
22 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
41.0 017-9075-00 017-9075-00 - Pillow Block Assembly (See Models Used On For Details)
$38.51
41.1 017-9000-00 017-9000-00 - Two Piece Pillow Block-Male
$10.99
41.2 017-9025-00 017-9025-00 - Two Piece Pillow Block-Plate
$32.09
41.3 017-9050-00 017-9050-00 - Two Piece Pillow Block-Female
$10.99
47 018-0043-00 018-0043-00 - 2 1/2 X 1/2 Carriage Bolt
$3.29
70 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
89 019-0007-00 019-0007-00 -.517 Square Hole Round Washer
$2.99
95 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
102 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
111 025-0002-00 025-0002-00 - Two-Piece Split Collar (See Models Used On For Details)
$10.91
113 025-0025-00 025-0025-00 - Round Spacer (See Models Used On For Details)
$7.28
127 028-0008-00 028-0008-00 - Deck Height Dial Rod Plunger (See Models Used On For Detail)
$31.17
128.0 028-0015-19 028-0015-19 - Deck Height Dial Rod Assembly 2019-2024 Rebel, Renegade & Rogue
$42.79
128.1 018-4011-00 018-4011-00 - 3/8-24 Zinc Nylon Insert Jam Locknut
$2.99
128.2 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
128.3 026-1101-00 026-1101-00 - Deck Height Cam
$15.55
128.4 028-0015-00 028-0015-00 - "R" Series Dial Rod 2019-2022 Rebel, Renegade & Rogue
$17.64
146 031-0125-00 031-0125-00 - Deck Travel Lock Lever 2019-2022 Rebel, Renegade & Rogue
$28.39
157 034-1025-00 034-1025-00 - Brake Spring (See Models Used On For Detail)
$12.48
168 044-4000-00 044-4000-00 - Locking Pin (See Models Used On)
$7.25
199 069-4011-00 069-4011-00 - Travel Lock Rubber Grip
$8.79
