2021 Renegade - Gas - Rear Cover & Battery

2021 Renegade - Gas - Rear Cover & Battery

The 2021 Renegade - Gas Rear Cover & Battery are integral parts that protect the mower’s inner components and provide the necessary power for operation. At BadBoyMowerParts.com, we offer a selection of high-quality Bad Boy Mower Parts for the 2021 Renegade - Gas. Our Bad Boy Mower Part diagrams make it easy to find the correct rear cover and battery parts for your mower. With our durable Bad Boy Lawn Mower Parts, your mower will stay in top condition. Shopping Bad Boy Parts Online allows for a seamless experience, and don’t forget that you’ll get Free Shipping On Orders Over $100, making it more affordable to get the parts you need.

Bad Boy Mower Parts Lookup

2021 Renegade - Gas - Rear Cover & Battery
  Position Number SKU Product Title Price
9 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
11 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
20 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
21 013-8051-00 013-8051-00 - 1/4-20 Wing Nuts Zinc
$2.99
27 014-2052-00 014-2052-00 - 2 x .25 Rubber Grommet (See Models Used On For Details)
$12.83
31 014-5063-00 014-5063-00 - Battery Hold Down Cover 2019-2025 Renegade
$10.99
33 014-9003-00 014-9003-00 - 1 1/2 x 3 Frame Plug
$2.99
46 018-0040-00 018-0040-00 - 1/2-13 x 8 1/2 Gr5 Hex Bolt
$7.18
48 018-0044-00 018-0044-00 - 3/8 x 2 1/2 Carriage Bolt
$2.99
70 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
85 018-8051-00 018-8051-00 - 1/4-20 X 9 Carriage Bolts Zinc
$2.99
86 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
97 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
115 025-0028-00 025-0028-00 - Pulley Spacer.75 x 4.375 x.5 ID 2019-2022 Renegade
$9.61
120 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
124 026-2224-00 026-2224-00 - Rear Side Cover 2019-2022 Renegade
$199.99
136 029-7038-00 029-7038-00 - 8 Bumper
$28.32
155 033-7027-00 033-7027-00 - Horizontal Rear V Pulley
$46.84
186 064-4000-00 064-4000-00 - Red Battery Cable (See Models Used On For Details)
$23.53
187 064-4001-00 064-4001-00 - Black Battery Cable (See Models Used On For Details)
$22.31
192.0 067-8052-19 067-8052-19 - Renegade Oil Cooler-Assy
$70.97
192.1 051-8063-14 051-8063-14 - 14" 3/8 Clear Hose No Clamp
$6.04
192.2 051-8063-24 051-8063-24 - 24" 3/8 Clear Hose No Clamps
$12.48
192.3 067-8052-00 067-8052-00 - 2019-2022 12" Oil Cooler With Fittings (See Models Used On For Details)
$62.46
192.4 072-8065-00 072-8065-00 - 3/8" Hose Clamp - CTB-16-STFS
$2.99
204 070-5373-19 070-5373-19 - 2019-2022 Horizontal Gas Frame Welded Assembly
$1461.53
