2021 Revolt - 61" Deck Assembly

2021 Revolt - 61" Deck Assembly

The 61" Deck Assembly for the 2021 Revolt offers a larger cutting area, making it a great choice for those with bigger lawns. At BadBoyMowerParts.com, we have everything you need for your 2021 Revolt deck, including top-tier Bad Boy Mower Parts. Our Bad Boy Mower Part diagrams will help you find the specific parts you need for any repair or replacement. We only stock Bad Boy Lawn Mower Parts that meet the highest standards, so you can count on your mower to deliver consistent results. When you shop Bad Boy Parts Online, you'll enjoy Free Shipping On Orders Over $100, making it easier to keep your mower running at peak performance.

Bad Boy Mower Parts Lookup

2021 Revolt - 61" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6048-00 088-6048-00 - Advanced Chute System for Revolt 48", 54", and 61" Decks
$249.00
1B 210-0361-00 210-0361-00 - Revolt/Rebel/Rogue/Renegade 61" Mulch Kit w/Blades
$318.45
1 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
2 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
3 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
4 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
5 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
6 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
7 014-4811-00 014-4811-00 - Trim Side Pulley Cover (See Models Used On For Details)
$16.04
8 014-4812-00 014-4812-00 - 54" Discharge Side Pulley Cover (See Models Used On For Detail)
$26.74
9 018-0046-00 018-0046-00 - 1/2-13 x 8" Hex Bolt
$4.06
10 018-0075-00 018-0075-00 - 3/8-16 x 1-3/4 Hex C/S () ZC
$3.29
11 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
12 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
13 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
14 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
15 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
16 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
17 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
18 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
19 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 Hex Bolts
$2.99
20 018-7060-00 018-7060-00 - 3/8-16 x 5 1/2 Hex Bolt -
$2.99
21 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
22 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
23 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
24 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
25 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
26 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
27 022-1001-00 022-1001-00 - Deck Wheel (See Models Used On For Detail)
$17.11
28 025-0025-00 025-0025-00 - Round Spacer (See Models Used On For Details)
$7.28
29 025-0032-00 025-0032-00 - Stationary Idler Spacer (See Models Used On For Details)
$8.46
30 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
31 029-7036-00 029-7036-00 - Deck Trim Bumper
$23.41
32 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
33 033-6004-00 033-6004-00 - 6 1/4" Spindle Deck Pulley (without set screw) (See Models Used On For Detail)
$35.48
34 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
35 034-2030-00 034-2030-00 - 2019-Newer Deck Spring (See Models Used On For Details)
$31.22
36 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$199.99
37.1 038-6081-00 038-6081-00 - 61" Gator Blade for Outlaw
$22.99
37 038-6080-00 038-6080-00 - 61" High Lift Fusion Blade
$22.99
38 039-2128-00 039-2128-00 - Stand On Deck Hanger Rear (See Models Used On For Details)
$14.19
39 039-2129-00 039-2129-00 - Stand On Deck Hanger Front (See Models Used On For Detail)
$16.04
40 039-6945-20 039-6945-20 - Idler Assembly (61" Deck)
$58.84
41 041-4022-00 041-4022-00 - B138 Deck Belt (See Models Used On For More Details, Not For 54" CZT/Stand-On)
$78.01
42 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
43 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
44 048-7000-00 048-7000-00 - Toplink-Outlaw Decks (See Models Used On For Details) (obsolete)
use part #048-8000-00
$80.24
45 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
47 210-7000-98 210-7000-98 - Chute Assembly (See Models Used On for Detail)
$159.22
