2021 Revolt - Front End

2021 Revolt - Front End

The 2021 Revolt Front End is critical for the stability and maneuverability of your mower, ensuring smooth performance on various terrains. At BadBoyMowerParts.com, we offer a wide selection of Bad Boy Mower Parts for your Revolt’s front-end assembly. Our Bad Boy Mower Part diagrams will help you find the specific components you need to keep the front end in optimal condition, from steering parts to pivot assemblies. For all your Bad Boy Lawn Mower Parts, we offer high-quality replacements that meet the demands of professional and residential lawn care. When you shop Bad Boy Parts Online, take advantage of Free Shipping On Orders Over $100, ensuring your parts arrive at no extra cost.

Bad Boy Mower Parts Lookup

2021 Revolt - Front End
  Position Number SKU Product Title Price
1 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
2 013-0026-00 013-0026-00 - 3/16" Diameter, for 0.1260"-0.25" Material
$3.29
3 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
4 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
5 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
6 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
7 014-2025-00 014-2025-00 - Caster Bearing Cover (See Models Used On For Details)
$2.99
8 018-0026-00 018-0026-00 - 1-14 X 5 1/2 BOLT GR 8
$13.90
9 018-0040-00 018-0040-00 - 1/2-13 x 8 1/2 Gr5 Hex Bolt
$7.18
9 018-8040-00 018-8040-00 - 1/4"X3/4" CARRIAGE BOLT
$2.99
10 018-0044-00 018-0044-00 - 3/8 x 2 1/2 Carriage Bolt
$2.99
11 018-0058-00 018-0058-00 - 1/4"-20 x 3/4 Black Oxide 18-8 Stainless Pan Head No Longer Available
Obsolete.
12 018-0072-00 018-0072-00 - 3/8-16 x 3 Carriage Bolt Zinc GR5
$2.99
13.0 022-2017-00 022-2017-00 - 13 x 6.50 - 6 Black Tire and Wheel Assembly
$94.15
13.1 022-5347-00 022-5347-00 - 13 x 6.50 - 6 Tire
$96.29
13.2 022-7007-00 022-7007-00 - 6 x 4.5 Black Wheel Small Bore (See Models Used On For Details)
$56.81
13.3 022-7009-00 022-7009-00 - 1 3/8" Small Bore Bearing-Hoosier
$13.36
14 023-1010-00 023-1010-00 - Front Fork 2019-2022 Revolt, 2021-2022 Maverick
$145.95
15 025-0003-00 025-0003-00 - Front Bearing Spacer
$14.04
16 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
17 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
18 026-0049-00 026-0049-00 - 2019-2022 Revolt Front Bumper Plate
$26.74
19 026-0084-00 026-0084-00 - Exhaust Shield Plate 2019-2022 Revolt
$13.90
20 026-0085-00 026-0085-00 - Exhaust Backer Plate
$16.04
21 029-7040-00 029-7040-00 - EZT Front Bumper (See Models Used On For Detail)
$31.17
22 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
23 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
26 070-9036-20 070-9036-20-36" Stand On Front End 2019-2022 Welded Assembly
$129.99
27 070-9048-19 070-9048-19 - 48" Stand On Front End 2019-2022 Welded Assembly
$129.99
28 070-9054-19 070-9054-19 - 54" Stand On Front End 2019-2022 Welded Assembly
$163.99
29 070-9061-20 070-9061-20 - 61" Stand On Front End 2020-2022 Welded Assembly (obsolete)
use part #070-9062-00
$229.99
