2021 Revolt - Podium Assembly - Detail

2021 Revolt - Podium Assembly - Detail

The Podium Assembly - Detail of the 2021 Revolt provides a closer look at the intricate design of the mower’s control panel and seating setup. It’s essential for maintaining the safety, comfort, and functionality of your machine. At BadBoyMowerParts.com, we offer a full selection of Bad Boy Mower Parts for the Podium Assembly. Our Bad Boy Mower Part diagrams help you quickly locate each component, from the seat base to the control panel housing. We carry all the Bad Boy Lawn Mower Parts necessary to ensure your 2021 Revolt stays in top shape. Plus, when you order Bad Boy Parts Online, you can take advantage of Free Shipping On Orders Over $100, saving you on delivery costs as you keep your mower running smoothly.

Bad Boy Mower Parts Lookup

2021 Revolt - Podium Assembly - Detail
  Position Number SKU Product Title Price
1 013-0001-00 013-0001-00 - 8-32 Hex Nut
$2.99
2 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
3 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
6 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
14 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
15 018-6049-00 018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc
$2.99
16 018-8040-00 018-8040-00 - 1/4"X3/4" CARRIAGE BOLT
$2.99
17 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
18 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
20 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
21 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
22 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
23 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
26 031-0026-00 031-0026-00 - Front Control Arm Stop 2019-2022 Revolt
$61.09
27 031-0027-00 031-0027-00 - Rear Control Arm Stop 2019-2022 Revolt
$46.00
28 031-0028-00 031-0028-00 - RH Drive Arm Actuator 2019-2022 Revolt
$42.52
29 031-0029-00 031-0029-00 - LH Drive Arm Actuator 2019-2022 Revolt
$42.52
30 031-0032-00 031-0032-00 - Drive Arm Bushing (Plastic Flange)
$7.28
31 031-0033-00 031-0033-00 - 36" Revolt Rear Control Arm Stop Weldmen No Longer Available
Obsolete.
32 031-0034-00 031-0034-00 - 36" Front Control Arm Stop Weldment--Bla
$32.05
33 031-0037-00 031-0037-00 - 36" RH Drive Arm Actuator Weldment
$32.05
34 031-0038-00 031-0038-00 - 36" Revolt LH Drive Arm Actuator Weldment
$32.05
35 031-0091-00 031-0091-00 - Drive Pivot Bar 2020-2022 Revolt
$35.48
36 031-0094-00 031-0094-00 - Revolt Drive Pivot Bar
$23.53
40 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
48 067-8090-03 067-8090-03 - Hydro Tank Assembly
$42.46
50 069-0002-00 069-0002-00 - Retractable Spring Plunger Black Steel 5/8-11
$84.52
52 069-2014-00 069-2014-00 - 2019-2022 Cushioned Grip (See Models Used On For Details)
$8.01
54 071-6005-00 071-6005-00 - Revolt Cup Holder (See Models Used On For Details)
$22.71
55 077-1000-00 077-1000-00 - Magnet-Steering Arm
$14.97
59 079-4106-00 079-4106-00 - RH Podium Panel 2019-2022 Revolt
$37.44
60 079-4111-00 079-4111-00 - LH Podium Panel 2019-2022 Revolt
$37.44
