2021 Revolt - Transaxle Assembly

2021 Revolt - Transaxle Assembly

The Transaxle Assembly in the 2021 Revolt is a critical component for ensuring the mower moves smoothly and efficiently. This assembly includes everything from gears to housing, making it essential for maintaining your mower’s driving power. At BadBoyMowerParts.com, we offer a complete selection of Bad Boy Mower Parts for the Transaxle Assembly. With our Bad Boy Mower Part diagrams, you can easily pinpoint the parts you need to maintain or replace. Whether you're replacing gears, seals, or the entire assembly, we carry a wide range of Bad Boy Lawn Mower Parts that fit the 2021 Revolt. Plus, enjoy Free Shipping On Orders Over $100 when purchasing Bad Boy Parts Online, ensuring your mower remains in peak condition.

Bad Boy Mower Parts Lookup

2021 Revolt - Transaxle Assembly
  Position Number SKU Product Title Price
1 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
1 085-4051-00 085-4051-00 - Hydro Service Package for 2020 and Older Models with Expansion Tanks - ZT2800, ZT3100, ZT3200, and all ZT3400
$104.74
2 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
3 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
4 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
5 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
7 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
8 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
9 014-9003-00 014-9003-00 - 1 1/2 x 3 Frame Plug
$2.99
10 018-0011-00 018-0011-00 - 1/4-20 x 2 Hex Bolt
$2.99
11 018-0056-00 018-0056-00 - 5/16x6 Carriage Bolt
$2.99
12 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
13 018-3000-00 018-3000-00 - 3/8-16 X 2 Hex Bolts Zinc
$2.99
14 018-4007-00 018-4007-00 - 1/4-20 X 1 Hex Bolts Zinc
$2.99
15 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
16 018-4701-00 018-4701-00 - 5/16-18 X 3 Hex Bolt Zinc
$2.99
17 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
18 018-6049-00 018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc
$2.99
19 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
20 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
21 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
22 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
23 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
24 022-4040-00 022-4040-00 - 23x9-12 Reaper Turf (See Models Used On for Details)
$329.99
25 022-4041-00 022-4041-00 - 36" Revolt Reaper Wheel Assy. 21x7x10
$195.99
26 024-1200-00 024-1200-00 - Fitting, 3/8 x 3/8 45 Degree, 4603-6-6 (See Models Used On For Details)
$19.93
27 025-0070-00 025-0070-00 - Transaxle Spacer
$6.41
28 025-2004-00 025-2004-00 - ACS Spacer 3/4x3/8x1/2
$15.60
29 025-7020-00 025-7020-00 - 5/8 Set Collar w/One Set Screw
$4.37
31 028-0071-00 028-0071-00 - Neutral Release Rod 2019-2024 Revolt
$29.95
32 034-1025-00 034-1025-00 - Brake Spring (See Models Used On For Detail)
$12.48
34 035-0006-19 035-0006-19 - Push-Rod Assembly
$46.84
35 039-0151-00 039-0151-00 - 2020 36" Brake Bracket--Black
$14.11
36 039-0212-00 039-0212-00 - Brake Bracket (See Models Used On For Details)
$25.54
37 039-6945-09 039-6945-09 - Pump Idler Assembly
$58.84
38 041-8000-00 041-8000-00 - Pump Belt (See Models Used On For Detail)
$80.24
39 041-8052-00 041-8052-00 - 2019-2025 Revolt Drive Belt, 48", 54", 61" Decks Only
$80.24
40 044-2004-00 044-2004-00 - Bow Pin
$2.99
41 050-2096-01 050-2096-01 - Left ZT Transaxle & 36" 2020-2022 Revolt
$729.99
42 050-2095-01 050-2095-01 - Right ZT Transaxle & 36" 2020-2022 Revolt
$729.99
43 050-6000-00 050-6000-00 - ZT3400 Transaxle - Left (obsolete)
use part #050-6000-02
$819.99
44 050-6001-00 050-6001-00 - ZT3400 Transaxle - Right (obsolete)
use part #050-6001-02
$819.99
45 064-3000-00 064-3000-00 - 44" Brake Cable
$31.22
