2021 ZT Elite - Drive Arms

2021 ZT Elite - Drive Arms

Your 2021 ZT Elite Drive Arms are critical to the mower's movement and functionality. If you’re looking for reliable replacement parts, BadBoyMowerParts.com offers a wide variety of Bad Boy Mower Parts to suit your needs. Whether you’re replacing the entire drive arm or individual components, we have the correct Bad Boy Lawn Mower Parts to ensure smooth operation. Our Bad Boy Mower Part diagrams make it easy to find and identify exactly what you need for your drive system. With Bad Boy Parts Online, ordering parts has never been easier, and we make it convenient to shop from the comfort of your own home. Take advantage of Free Shipping On Orders Over $100 and get your parts delivered directly to your door. Don’t let your 2021 ZT Elite experience performance issues – trust BadBoyMowerParts.com to keep it running at its best.

Bad Boy Mower Parts Lookup

2021 ZT Elite - Drive Arms
  Position Number SKU Product Title Price
2 013-0010-00 013-0010-00 - 1/2-13 Mechanical Lock Nut
$2.99
7 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
11 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
12 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
14 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
20 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
49 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
55 018-2055-00 018-2055-00 - 10mm Damper Stud-XP Linkage
$2.99
59 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
60 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
74 018-8063-00 018-8063-00 - 5/16-18 X 3/4 Hex Bolt
$2.99
81 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
82 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
84 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
88 019-8027-00 019-8027-00 -.515 ID Plastic Shoulder Washer
$2.99
92 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
120 031-0017-01 031-0017-01 - Left Steering Arm Assembly (See Models Used On for Details)
$145.99
121 031-0018-01 031-0018-01 - Right Steering Arm Assembly (See Models Used On for Details)
$145.99
132 034-8025-00 034-8025-00 - Drive Lever Housing Spring
$4.07
134 035-5450-00 035-5450-00 - Right Steering Push Rod (See Models Used On For Details)
$33.95
135 035-5451-00 035-5451-00 - Left Steering Push Rod (See Models Used On For Details)
$42.58
180 070-5421-00 070-5421-00 - 2021 Suspension ZT Frame--Painted
$1199.99
182 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
189 087-0001-00 087-0001-00 - Steering Damper (See Models Used On For Details)
$62.40
