2021 ZT Elite - Floorboard & Front Pivots

2021 ZT Elite - Floorboard & Front Pivots

Maintaining the 2021 ZT Elite Floorboard & Front Pivots is essential for a comfortable and safe mowing experience. At BadBoyMowerParts.com, we offer an extensive range of Bad Boy Mower Parts, including replacements for floorboards and front pivots. Our Bad Boy Mower Part diagrams help you easily locate the parts needed for your 2021 ZT Elite. Whether you're replacing worn-out floorboards or repairing the front pivots, our Bad Boy Lawn Mower Parts ensure your mower operates as it should. Bad Boy Parts Online offers a convenient way to find and order your parts, with an intuitive shopping experience. Plus, you can enjoy Free Shipping On Orders Over $100, making it even more affordable to maintain your mower. Keep your 2021 ZT Elite in peak condition with high-quality parts from BadBoyMowerParts.com, designed to fit your mower perfectly.

Bad Boy Mower Parts Lookup

2021 ZT Elite - Floorboard & Front Pivots
  Position Number SKU Product Title Price
141.0 039-5944-01 039-5944-01 - Pump Idler Bracket Assy (See Models Used On For Details)
$62.46
141.1 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
141.2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
141.3 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
141.4 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
141.5 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
141.6 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
141.7 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
141.8 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
173.0 067-0020-01 067-0020-01 - 2019-2025 ZT/Maverick EPA Cannister Assy, Also Fits 2019-2021 Compact Outlaw
$85.59
173.1 051-2020-01 051-2020-01 - 1/4 Vinyl 46" EPA Line (See Models Used On For Details)
$12.48
173.2 051-2025-02 051-2025-02 - 3/16 Vinyl 55" EPA Line
$12.48
173.3 067-0020-00 067-0020-00 - Carbon Canister
$62.40
173.4 072-8070-00 072-8070-00 - Tank Hose Clamp 3/16 (See Models Used On For Detail)
$2.99
173.5 072-8073-00 072-8073-00 - 3/16" Vinyl Hose Clamp
$2.99
185.0 079-3470-20 079-3470-20 - 2021 ZT ELITE Floorboard Assembly No Longer Available
Obsolete.
185.1 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
185.2 079-3470-18 079-3470-18 - Floor Panel 2018-2024 Maverick, 2021-2024 ZT Elite
$106.99
185.3 081-4000-00 081-4000-00 - 2017-2021 Floor Mat (See Models Used On For Details)
$62.48
213.0 250-1751-21 250-1751-21 2021-2024 ZT Suspension Arm Assy. Short Right
$109.99
213.1 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
213.2 014-3010-00 014-3010-00 - 5/8 Round Insert
$2.99
213.3 025-0003-00 025-0003-00 - Front Bearing Spacer
$14.04
214.0 250-1801-21 250-1801-21 - 2021-2022 ZT Suspension Arm Assembly Left
$106.99
215.0 250-1851-21 250-1851-21 - 2021-2022 ZT Suspension Arm Assembly Long Right (54 & 60 Decks)
$106.99
