2021 ZT Elite - Seat & Console Detail

2021 ZT Elite - Seat & Console Detail

The 2021 ZT Elite Seat & Console Detail are integral to the comfort and functionality of your mower. If you need to replace or repair the seat or console, BadBoyMowerParts.com has you covered with a full range of Bad Boy Mower Parts. We offer durable, high-quality Bad Boy Lawn Mower Parts designed to fit the 2021 ZT Elite perfectly. Our detailed Bad Boy Mower Part diagrams allow you to quickly identify the specific parts you need for your mower’s seat and console. Shopping for Bad Boy Parts Online is fast and convenient, ensuring you get the right parts with ease. Plus, enjoy Free Shipping On Orders Over $100, making your purchase even more affordable. Whether it’s a new seat, a console replacement, or any other part, BadBoyMowerParts.com is your go-to destination for maintaining your 2021 ZT Elite in top condition.

Bad Boy Mower Parts Lookup

2021 ZT Elite - Seat & Console Detail
  Position Number SKU Product Title Price
39.0 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
39.1 017-9077-00 017-9077-00 - Pillow Block-Male
$21.28
39.2 017-9078-00 017-9078-00 - Pillow Block-Female (obsolete)
use part #017-9077-00
$21.28
39.3 017-9079-00 017-9079-00 - Pillow Block-Metal Plate
$21.28
105.0 026-0019-01 026-0019-01 - Foot Pedal Assembly (See Models Used On For Details)
$93.69
105.1 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
105.2 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
105.3 026-0019-00 026-0019-00 - Shallow Foot Pedal (See Models Used On For Detail)
$31.22
105.4 031-0500-00 031-0500-00 - 2017-2024 Deck Pedal Lever (See Models Used On For Detail)
$31.22
113.0 028-0070-17 028-0070-17 - Deck Height Bar Assy. (See Models Used On for Details)
$29.66
113.1 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
113.2 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
113.3 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
113.4 026-1100-00 026-1100-00 - 2017-Newer CAM Plate Use With Deck Adjuster (See Models Used On For Detail)
$15.55
113.5 028-0014-00 028-0014-00 - Deck Height Dial Rod (See Models Used For Detail)
$31.17
133.0 034-8045-03 034-8045-03 - Seat Spring Assembly (See Models Used On For Detail)
$32.09
133.1 013-0017-00 013-0017-00 - 3/8-16 Half Jam Nut
$2.99
133.2 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
133.3 018-3000-00 018-3000-00 - 3/8-16 X 2 Hex Bolts Zinc
$2.99
133.5 034-8045-00 034-8045-00 - Seat Spring
$20.49
156.0 051-0001-00 051-0001-00 - Fuel Line-15" (See Models Used On For Details)
$40.53
156.1 051-8067-00 051-8067-00 - 1/4 Fuel Line Hose (Priced by the Foot)
$6.41
156.2 072-8069-00 072-8069-00 - 1/4 Fuel Line Clamp
$2.99
157.0 051-2014-00 051-2014-00 - 37" Fuel Line Assembly (See Models Used On For Details)
$40.53
157.1 051-2014-01 051-2014-01 - 37" 1/4 Fuel Line (No Clamp)
$19.25
175.0 067-2021-00 067-2021-00 - 2021-2024 Maverick Left Side Tank
$349.99
175.1 066-8083-00 066-8083-00 - 3.5" Tethered Fuel Cap
$23.53
175.2 067-0011-00 067-0011-00 - Fuel Line Pickup Tube
$23.41
175.3 067-4090-00 067-4090-00 - Fuel Gauge (See Models Used On For Details)
$46.00
175.4 067-6070-00 067-6070-00 - Rollover Valve and Grommet New
$24.60
175.5 067-6080-00 067-6080-00 - Grommet for ZT Elite Fuel Line Pickup Tube
$8.01
177.0 069-1051-21 069-1051-21 - Load Balanced Brake Handle Assembly
$70.97
177.1 013-0012-00 013-0012-00 - 3/8-16 Centerlock Half Nut
$3.29
177.2 013-8042-00 013-8042-00 - 5/16-18 Nylon Insert Cap Locknut Zinc (Black Cap)
$2.99
177.4 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
177.5 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
177.8 025-0001-00 025-0001-00 - Brake Lever Spacer (See Models Used On For Detail)
$8.01
177.9 032-5053-00 032-5053-00 - Bronze Bushing SF-1220-8 2013 & UP CZT/ZT Brake Bushing
$2.99
177.10 039-0170-00 039-0170-00 - Brake Cable Extension Plate
$10.99
177.11 039-0171-00 039-0171-00 - Brake Load Balancer Weldment
$10.99
177.13 069-3010-00 069-3010-00 - Brake Handle Rubber
$18.45
181.0 071-2101-00 071-2101-00 - 2021-2024 ZT Elite Seat
$625.99
181.2 071-8061-00 071-8061-00 - Seat Switch (See Models Used On For Detail)
$19.14
181.3 071-2054-00 071-2054-00 - Arm Rest Kit (See Models Used On For Details) (obsolete)
use part #071-2119-00
$139.99
181.4 071-2101-02 071-2101-02 - Back Cover for 071-2101-00
$96.29
181.5 071-2102-02 071-2102-02 - Seat Cover (See Models Used On For Details)
$131.37
181.6 071-5015-00 071-5015-00 - Seat Rails
$93.69
181.7 039-2157-00 039-2157-00 - Black Seat stop
$14.19
184.0 079-3460-19 079-3460-19 - 2019-2022 ZT/Maverick Control Panel Assy, Also Fits 2019-2021 Compact Outlaw, and 2022 MZ/MZ Magnum
$144.63
184.1 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
184.2 018-1040-00 018-1040-00 - Light Plug
$2.99
184.3 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
184.5 056-8058-00 056-8058-00 - PTO Engager-Switch for Blades
$34.29
184.6 077-8076-00 077-8076-00 - 3-Position Ignition Switch (key not included)
$21.39
184.7 079-3460-00 079-3460-00 - Control Panel (See Models Used On For Details)
$23.53
184.8 083-4013-00 083-4013-00 - Tachometer-N211-0100-1003
$74.89
184.9 091-0338-18 091-0338-18 - Control Panel Decal 2018-2021 MZ/Magnum/ZT/Maverick
$14.97
188.0 086-3050-19 086-3050-19 - 2019-2023 MZ/ZT/Maverick/Compact Outlaw Wiring Harness (obsolete)
use part #086-3600-00
$299.99
188.1 086-1202-01 086-1202-01 - 2019-2024 Relay Cap Kit
$18.45
188.2 086-1202-19 086-1202-19 - Relay Terminal
$24.97
188.3 086-3050-00 086-3050-00 - Wiring Harness- ZT 2007 and Up (obsolete)
use part #086-3050-17
$299.99
