2022 Maverick - Drive Arm - Detail

2022 Maverick - Drive Arm - Detail

The 2022 Maverick Drive Arm - Detail components are essential for smooth handling and precise mower control. If you're experiencing difficulty with maneuverability, it may be time to replace worn or damaged parts. At BadBoyMowerParts.com, we offer a full range of Bad Boy Mower Parts designed for a perfect fit. Our Bad Boy Mower Part diagrams allow you to pinpoint the exact drive arm components needed for repairs. High-performance Bad Boy Lawn Mower Parts ensure that your machine operates with maximum responsiveness and reliability. With our large selection of Bad Boy Parts Online, you can quickly locate and order the necessary drive arm parts without hassle. Plus, take advantage of Free Shipping On Orders Over $100 to get the best value on essential mower components. Restore your 2022 Maverick Drive Arm - Detail to factory condition with our trusted replacement parts!

Bad Boy Mower Parts Lookup

2022 Maverick - Drive Arm - Detail
  Position Number SKU Product Title Price
113.0 031-0053-21 031-0053-21 - 2021-2022 Maverick Drive Arm Actuator RH Assembly
$42.79
113.1 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
113.2 018-8063-00 018-8063-00 - 5/16-18 X 3/4 Hex Bolt
$2.99
113.3 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
113.4 031-0032-00 031-0032-00 - Drive Arm Bushing (Plastic Flange)
$7.28
113.5 031-0053-00 031-0053-00 - 2021 Maverick Drive Actuator RH Weldment No Longer Available
Obsolete.
114.0 031-0054-21 031-0054-21 - 2021-2022 Maverick Drive Arm Actuator LH Assembly
$42.79
114.5 031-0054-00 031-0054-00 - 2021 Maverick Drive Actuator LH Weldment No Longer Available
Obsolete.
116.0 031-9000-18 031-9000-18 - Left Adjustable Steering Arm (See Models Used On For Details)
$144.50
116.1 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc
$2.99
116.2 018-2020-18 018-2020-18 - 5/16-18 x 1 3/8" Button Head Torx Drive
$2.99
116.3 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
116.4 031-9010-18 031-9010-18 - Upper Steering Arm (See Models Used On For Details)
$28.32
116.5 031-9014-18 031-9014-18 - Black Lower Adjuster Steering Arm 2019-2022 Maverick, Compact Outlaw
$53.24
116.6 031-9017-18 031-9017-18 - Black Upper Adjuster - Steering Arm (See Models Used On For Details)
$53.24
116.7 031-9020-18 031-9020-18 - Left Black Steering Arm Elbow
$85.17
116.8 045-5000-00 045-5000-00 - Knob - Adjustable Steering Arm
$5.49
116.9 069-4010-00 069-4010-00 - Black Steering Grip
$8.12
117.0 031-9050-18 031-9050-18 - 2017 - 2022 Right Adjustable Steering Arm Black
$144.50
117.5 031-9015-18 031-9015-18 - Left Lower Steering Arm Adjuster Black
$53.24
117.6 031-9016-18 031-9016-18 - Black Upper Adjuster - Steering Arm (See Models Used On For Details)
$53.24
117.7 031-9025-18 031-9025-18 - 2019 and Newer Black Steering Arm Elbow - Right
$85.17
132.0 035-5450-00 035-5450-00 - Right Steering Push Rod (See Models Used On For Details)
$33.95
132.1 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
132.3 048-3000-00 048-3000-00 - Spherical Rod End (See Models Used On For Details)
$14.19
132.4 099-2009-00 099-2009-00 - Quick Release Ball Joint (See Models Used On For Details)
$9.89
133.0 035-5451-00 035-5451-00 - Left Steering Push Rod (See Models Used On For Details)
$42.58
