2022 Maverick - Front Axle, Floorboard & Rear Plate

2022 Maverick - Front Axle, Floorboard & Rear Plate

The 2022 Maverick Front Axle, Floorboard & Rear Plate play a vital role in the stability and durability of your mower. If any of these components become worn or damaged, replacing them with genuine Bad Boy Mower Parts will restore the mower’s structural integrity. At BadBoyMowerParts.com, we provide detailed Bad Boy Mower Part diagrams to help you locate the exact parts needed for repairs. Investing in high-quality Bad Boy Lawn Mower Parts ensures long-lasting performance and prevents future issues. Shopping for Bad Boy Parts Online is quick and hassle-free with our well-organized inventory. Plus, take advantage of Free Shipping On Orders Over $100, so you can save money while keeping your 2022 Maverick Front Axle, Floorboard & Rear Plate in top condition. Don’t let worn-out parts compromise your mower—get the best replacement components from our trusted selection today!

Bad Boy Mower Parts Lookup

2022 Maverick - Front Axle, Floorboard & Rear Plate
  Position Number SKU Product Title Price
99.0 026-0205-22 026-0205-22 - 2022 Maverick Rear Cover Assembly
$189.99
99.1 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
99.2 014-5300-00 014-5300-00 - 2021-2022 Maverick Rear Cover Assembly
$222.99
99.3 018-5044-00 018-5044-00 - 3/8 x 1 Carriage Bolt
$2.99
99.4 026-0226-00 026-0226-00 Rear Cover Side Plate - Painted
$42.79
143.0 039-5944-05 039-5944-05 - Pump Idler Bracket Assy-EZT
$70.97
143.1 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
143.2 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
143.4 018-0015-00 018-0015-00 - 1/2-13 x 2 1/2 Hex Bolt
$2.99
143.5 018-6016-00 018-6016-00 - 5/8 x 5 1/2 Bolt
$2.99
143.6 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
143.7 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
143.8 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
143.9 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
143.10 033-8000-00 033-8000-00 - 5 3/4 Pump Idler Pulley-5/8 Bore 2016-2025 Maverick
$35.48
143.11 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
173.0 067-0020-01 067-0020-01 - 2019-2025 ZT/Maverick EPA Cannister Assy, Also Fits 2019-2021 Compact Outlaw
$85.59
173.1 051-2020-01 051-2020-01 - 1/4 Vinyl 46" EPA Line (See Models Used On For Details)
$12.48
173.2 051-2025-02 051-2025-02 - 3/16 Vinyl 55" EPA Line
$12.48
173.3 067-0020-00 067-0020-00 - Carbon Canister
$62.40
173.4 072-8070-00 072-8070-00 - Tank Hose Clamp 3/16 (See Models Used On For Detail)
$2.99
173.5 072-8073-00 072-8073-00 - 3/16" Vinyl Hose Clamp
$2.99
185.0 079-3470-21 079-3470-21 - 2021 Maverick Floorboard Assembly
$159.99
185.1 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
185.2 079-3470-18 079-3470-18 - Floor Panel 2018-2024 Maverick, 2021-2024 ZT Elite
$106.99
185.3 081-4001-00 081-4001-00 - 2021-2024 Floor Mat W/ Reaper Tread
$53.49
215.0 250-2751-21 250-2751-21 - 2021 Maverick RH Arm Assembly - Short
$199.99
215.1 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
215.2 025-0003-00 025-0003-00 - Front Bearing Spacer
$14.04
215.3 250-2751-00 250-2751-00 - I-Beam Front Arm Short-RH--Painted
$129.99
216.0 250-2801-21 250-2801-21 - 2021 and Newer Maverick LH Front Suspension Arm Assy
$132.68
216.3 250-2801-00 250-2801-00 - I-Beam Front Arm-LH--Painted (See Models Used On For Details)
$93.64
217.0 250-2851-21 250-2851-21 - 2021 and Newer Maverick RH Long Front Suspension Arm Assy
$149.99
217.3 250-2851-00 250-2851-00 - I-Beam Front Arm Long-RH--Painted
$93.64
