2022 Maverick HD - Engine - Kohler CV742

2022 Maverick HD - Engine - Kohler CV742

The 2022 Maverick HD Engine - Kohler CV742 is designed to provide reliable power and efficiency for your lawn care needs. If you need to replace any components of this engine, BadBoyMowerParts.com is your trusted source for Bad Boy Mower Parts. We offer a comprehensive selection of Bad Boy Lawn Mower Parts, specifically for the Kohler CV742 engine, including air filters, oil filters, and fuel lines. To make your part selection process easy, our website includes Bad Boy Mower Part diagrams, allowing you to quickly identify and order the exact parts needed for your mower. Shopping for Bad Boy Parts Online is simple, and our parts are always of the highest quality. Plus, with Free Shipping On Orders Over $100, you can enjoy significant savings while keeping your 2022 Maverick HD engine in top condition. Visit BadBoyMowerParts.com today for all your engine replacement needs.

Bad Boy Mower Parts Lookup

2022 Maverick HD - Engine - Kohler CV742
  Position Number SKU Product Title Price
1A 063-2000-09 063-2000-09 - Kohler Command (Non-EFI Models)
$121.25
2A 055-8020-00 055-8020-00 - Throttle Cable-53" (See Models Used On For Details)
$38.97
2B 054-8017-00 054-8017-00 - 62" Choke Cable (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$25.80
4 013-0075-00 013-0075-00 - M8 - 1.25 Zinc Nut
$3.29
15 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
19 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
29 015-0051-00 015-0051-00 - 2017-2024 Kohler Exhaust MZ/ZT/Maverick
$217.48
36.1 015-2751-00 015-2751-00 - Exhaust Gasket for 27,30 hp Kohler Engines
$6.56
36.2 015-8000-00 015-8000-00 - Spark Plug (RC12YC or Equivalent)
$13.90
36.3 063-5001-00 063-5001-00 - Kohler Fuel Filter
$19.25
36.4 063-5400-00 063-5400-00 - Oil Filter (Long) for Kohler Engines
$22.46
36.5 063-8019-00 063-8019-00 - Outer Air Filter, Fits all except 23 Briggs/Diesel
$35.84
36.6 063-8020-00 063-8020-00 - Inner Canister Air Filter - Fits All except 23 Briggs/Diesel
$32.65
36 015-7420-00 015-7420-00 - Kohler 25Hp CV-742 Command No Longer Available
Obsolete.
47 018-1075-00 018-1075-00 - 3/8 x 1 1/8 Engine Mounting Bolt
$2.99
66 018-5350-00 018-5350-00 - 5/16-18 X 5-1/2 Hex Bolt
$2.99
67 018-5450-21 018-5450-21 - 7/16-20 x 1.5" Hex bolt GR 8 w/ Patch
$2.99
73 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
89 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
116 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
128 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley - Extended Shaft (See Models Used On For Details)
$42.58
158 041-7400-00 041-7400-00 - Pump Belt for Maverick and Maverick HD
$64.19
159 042-5020-00 042-5020-00 - 1/4 X 2 Square Key Stock
$2.99
162 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
171 051-5401-00 051-5401-00 - Kohler/Briggs Oil Drain Hose
$31.17
180 064-0030-00 064-0030-00 - 24 inch Black Battery Cable
$18.72
183 064-8060-00 064-8060-00 - 36" Red Battery Cable (See Models Used On For Details)
$20.93
191 070-1000-00 070-1000-00 - PTO Clutch (See Models Used On For Details)
$279.99
192 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
193 070-5492-00 070-5492-00 - 2022 Maverick Frame--Painted
$799.99
205 086-9005-00 086-9005-00 - C-Outlaw Starter Jumper Wire
$23.53
