2022 Maverick - Transaxle Assembly

2022 Maverick - Transaxle Assembly

The 2022 Maverick Transaxle Assembly is essential for smooth power transfer and maneuverability, ensuring a reliable and efficient mowing experience. If your transaxle is slipping, leaking, or malfunctioning, replacing it with genuine Bad Boy Mower Parts will restore your mower’s performance. At BadBoyMowerParts.com, we provide clear Bad Boy Mower Part diagrams to help you quickly locate the correct transaxle components for easy repair. Using high-quality Bad Boy Lawn Mower Parts ensures durability and longevity, preventing costly breakdowns. Shopping for Bad Boy Parts Online allows you to find exactly what you need without hassle. Plus, we offer Free Shipping On Orders Over $100, helping you save while maintaining your mower’s drivetrain. Keep your 2022 Maverick Transaxle Assembly in peak condition with premium replacement parts from our extensive inventory!

Bad Boy Mower Parts Lookup

2022 Maverick - Transaxle Assembly
  Position Number SKU Product Title Price
1 085-4051-01 085-4051-01 - Hydro Service Kit for 2021 & Newer ZT Avenger, ZT Elite & Maverick Models (Without Expansion Tanks)
$125.99
5 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
6 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
8 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
9 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
15 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
16 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
43 018-1055-00 018-1055-00 - 1/2 x 3/4 Bolt
$2.99
52 018-2071-00 018-2071-00 - 3/8 x 2 1/2 Hex Tap Bolt - Ful l Thread - ACS
$2.99
53 018-4701-00 018-4701-00 - 5/16-18 X 3 Hex Bolt Zinc
$2.99
61 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
68 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
77 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
81 019-8027-00 019-8027-00 -.515 ID Plastic Shoulder Washer
$2.99
83 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
88.0 022-4040-00 022-4040-00 - 23x9-12 Reaper Turf (See Models Used On for Details)
$329.99
88.1 022-3011-00 022-3011-00 - 12x7" Black Wheel-48" EZT Only
$109.99
88.2 022-4035-00 022-4035-00 - 23x9 - 12 Reaper Turf Tire Only
$201.99
89.0 022-4200-00 022-4200-00 - 23x11-12 Reaper Tire/Wheel Assembly (See Models Used On For Details)
$320.99
89.1 022-4070-00 022-4070-00 - Black Wheel 12x8.5 (See Models Used On for Detail)
$141.99
89.2 022-4195-00 022-4195-00 - 23x11-12 Reaper Turf Tire
$255.99
92 025-0036-00 025-0036-00 - Drive Arm Transaxle Spacer
$5.49
118 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
119 032-9000-00 032-9000-00 - Isolator - Green Dot
$70.97
120 032-9002-00 032-9002-00 - Isolator - Red Dot
$70.97
127 034-1026-00 034-1026-00 - Brake Return Spring (See Models Used On For Details)
$14.19
138 039-0001-00 039-0001-00 - Rear Transaxle Pivot Bracket
$15.60
139 039-1306-00 039-1306-00 - EZT Rear Susp Transaxle Mount
$15.60
140 039-1320-00 039-1320-00 - Brake Arm Extension Bracket [Maverick LH]
$6.04
141 039-1321-00 039-1321-00 - Brake Arm Ext Bracket Right Side
$8.01
149 041-7400-00 041-7400-00 - Pump Belt for Maverick and Maverick HD
$64.19
154 044-2004-00 044-2004-00 - Bow Pin
$2.99
155 044-2008-00 044-2008-00 - Neutral Rod Clip
$2.99
157.1 034-9080-00 034-9080-00 - Gold Transaxle Spring
$14.89
157.2 050-2070-00 050-2070-00 - 2020 -2024 ZT Avenger/ ZT/Maverick Transaxle Fan/Pulley Kit
$85.17
157.3.1 050-2012-00 050-2012-00 - Transaxle Wheel Studs/ Drum Brake Studs
$5.61
157.3 050-2077-00 050-2077-00 - 5 Bolt Hub Kit (See Models Used On For Details)
$102.71
157.4 050-8010-00 050-8010-00 - ZT/Maverick Transaxle Seal Kit (ZT-2800)
$109.46
157.5 063-1050-00 063-1050-00 - ZT Hydraulic Filter
$22.71
157 050-0075-02 050-0075-02 - 2021-2022 LH 3200 Transaxle
$799.99
158 050-0080-02 050-0080-02 - 2021-2022 RH 3200 Transaxle
$999.99
169 064-3050-21 064-3050-21 - 2021-2025 Load Balanced Brake Cable 1
$56.77
170 064-3051-21 064-3051-21 - 2021-2025 Load Balanced Brake Cable 2
$56.77
180 070-5492-00 070-5492-00 - 2022 Maverick Frame--Painted
$799.99
