2022 Rebel - Drive Arm - Detail

2022 Rebel - Drive Arm - Detail

The 2022 Rebel Drive Arm - Detail plays a critical role in the mower's maneuverability, ensuring smooth and responsive handling. If you need to repair or replace this essential component, our Bad Boy Mower Part diagrams provide a clear reference for accurate installation. At BadBoyMowerParts.com, we stock an extensive selection of Bad Boy Mower Parts, including high-quality drive arms for reliable performance. Keeping your mower in top shape requires durable Bad Boy Lawn Mower Parts, and we offer only the best. With easy access to Bad Boy Parts Online, ordering the right components has never been simpler. Plus, enjoy Free Shipping On Orders Over $100, so you can get essential parts delivered without additional costs. Whether you need bushings, bolts, or a full replacement, trust our premium inventory to keep your 2022 Rebel Drive Arm - Detail operating smoothly.

Bad Boy Mower Parts Lookup

2022 Rebel - Drive Arm - Detail
  Position Number SKU Product Title Price
151.0 031-0030-19 031-0030-19 - R Series Right Arm Rod Assembly (See Models Used On For Details)
$85.17
151.1 013-0017-00 013-0017-00 - 3/8-16 Half Jam Nut
$2.99
151.2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
151.3 018-0063-00 018-0063-00 - 3/8-16 X 1 Socket Set Screw Cup Point
$2.99
151.4 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
151.5 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
151.6 031-0014-00 031-0014-00 - Drive Arm Pivot 2019-2022 Rebel, Renegade & Rogue
$24.92
151.7..3 031-0032-00 031-0032-00 - Drive Arm Bushing (Plastic Flange)
$7.28
151.7.1 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
152.0 031-0031-19 031-0031-19 - R Series Left Arm Rod Assembly, 2019-2023 Rebel/Renegade/Rogue
$85.17
154.0 031-9005-70 031-9005-70 - Left Hand Adjustable Steering Arm Kit 2019-2022 Rebel, Renegade & Rogue
$132.68
154.1 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc
$2.99
154.2 018-2020-18 018-2020-18 - 5/16-18 x 1 3/8" Button Head Torx Drive
$2.99
154.3 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
154.4 031-9005-00 031-9005-00 - Upper/Lower Steering Arm Casting 2019-2023 Rebel, Renegade & Rogue
$28.39
154.5 031-9006-00 031-9006-00 - Steering Arm Tube
$42.79
154.6 045-5000-00 045-5000-00 - Knob - Adjustable Steering Arm
$5.49
154.7 069-4010-00 069-4010-00 - Black Steering Grip
$8.12
155.0 031-9055-70 031-9055-70 - Right Hand Adjustable Steering Arm Kit 2019-2022 Rebel, Renegade & Rogue
$115.31
167.0 035-0003-00 035-0003-00 - 2019 - 2022 Rebel Push Rod Assembly
$42.58
167.1 013-6050-00 013-6050-00 - 5/16 LH Nut For Push Rods
$4.39
167.2 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
167.3 035-0003-01 035-0003-01 - 2019-2023 Rebel Rigid Push Rod
$35.30
167.4 048-3000-00 048-3000-00 - Spherical Rod End (See Models Used On For Details)
$14.19
167.5 048-3002-00 048-3002-00 - Spherical Rod End - LH Thread (See Models Used On For Details)
$32.09
