2022 Rogue - Drive Arm Assembly

2022 Rogue - Drive Arm Assembly

The 2022 Rogue Drive Arm Assembly is a key component in the mower's drivetrain, ensuring that the wheels receive proper power for forward motion. At BadBoyMowerParts.com, we offer a comprehensive range of Bad Boy Mower Parts, including the complete 2022 Rogue Drive Arm Assembly. With our Bad Boy Mower Part diagrams, locating the correct assembly or individual parts for repair is quick and easy. Whether you need a full replacement or specific components like bushings or bearings, we have the necessary Bad Boy Lawn Mower Parts for your 2022 Rogue. Shop Bad Boy Parts Online for added convenience, and enjoy Free Shipping On Orders Over $100 to keep your mower in top working condition.

Bad Boy Mower Parts Lookup

2022 Rogue - Drive Arm Assembly
  Position Number SKU Product Title Price
3 013-0021-00 013-0021-00 - Extruded Nut 3/8"-16 3/4"
$4.39
16 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
17 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc
$2.99
19 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
22 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
66 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
68 018-2006-00 018-2006-00 - 5/16-18 X 1-1/4 Hex Bolt
$2.99
74 018-2020-18 018-2020-18 - 5/16-18 x 1 3/8" Button Head Torx Drive
$2.99
85 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
106 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
117 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
143 028-0051-00 028-0051-00 - Steering Actuator Rod 2019-2025 Rebel, Renegade & Rogue
$23.41
156 031-0030-19 031-0030-19 - R Series Right Arm Rod Assembly (See Models Used On For Details)
$85.17
157 031-0031-19 031-0031-19 - R Series Left Arm Rod Assembly, 2019-2023 Rebel/Renegade/Rogue
$85.17
159 031-9005-70 031-9005-70 - Left Hand Adjustable Steering Arm Kit 2019-2022 Rebel, Renegade & Rogue
$132.68
160 031-9055-70 031-9055-70 - Right Hand Adjustable Steering Arm Kit 2019-2022 Rebel, Renegade & Rogue
$115.31
162 032-0002-00 032-0002-00 - Snap-In Bushing 2019-2022 Rebel, Renegade & Rogue
$15.55
175 035-0004-00 035-0004-00 - 2019-2022 Rogue Push Rod Assembly
$42.58
185 039-2160-00 039-2160-00 - Arm Switch Bracket (See Models Used On For More Detail)
$13.90
215 057-5800-00 057-5800-00 - Speed Limiting Knob 3/8-16X 3"
$6.41
238 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
255 087-0002-00 087-0002-00 - Steering Rod Damper With Spherical Rod Ends For Renegade/Rogue (See Models Used On For Details)
$62.46
261 091-0015-22 091-0015-22 - EPA Build Date Punch Label
$3.62
265 091-1020-00 091-1020-00 - Hydraulic Decal (See Models Used On For Details)
$2.99
267 091-1114-00 091-1114-00 - 2018-2022 LH/RH Steering Control Decal Roll
$15.60
277 091-4028-00 091-4028-00 - 2019-2022 Rogue Cooler Cover Decal
$12.48
280 091-4037-00 091-4037-00 - 2019-2022 Deck Release Decal
$8.01
