2022 ZT Elite - Floorboard & Front Pivots

2022 ZT Elite - Floorboard & Front Pivots

The 2022 ZT Elite Floorboard & Front Pivots are essential for the durability and comfort of your mower. If you need replacement parts or upgrades, BadBoyMowerParts.com is your one-stop shop for all Bad Boy Mower Parts. Our detailed Bad Boy Mower Part diagrams make it simple to locate the floorboard and pivot components that match your 2022 ZT Elite. Whether you need to replace a worn-out floorboard or fix front pivots, we carry high-quality Bad Boy Lawn Mower Parts that ensure long-lasting performance. Shopping for Bad Boy Parts Online is hassle-free, and we offer a wide range of parts to meet your needs. Plus, enjoy Free Shipping On Orders Over $100 on eligible items, so you can keep your mower in top condition without worrying about extra shipping fees. Keep your 2022 ZT Elite Floorboard & Front Pivots in prime shape for a smooth, efficient mowing experience.

Bad Boy Mower Parts Lookup

2022 ZT Elite - Floorboard & Front Pivots
  Position Number SKU Product Title Price
118.2 079-3470-18 079-3470-18 - Floor Panel 2018-2024 Maverick, 2021-2024 ZT Elite
$106.99
144.0 039-5944-01 039-5944-01 - Pump Idler Bracket Assy (See Models Used On For Details)
$62.46
144.1 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
144.2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
144.3 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
144.4 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
144.5 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
144.6 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
144.7 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
144.8 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
176.0 067-0020-01 067-0020-01 - 2019-2025 ZT/Maverick EPA Cannister Assy, Also Fits 2019-2021 Compact Outlaw
$85.59
176.1 051-2020-01 051-2020-01 - 1/4 Vinyl 46" EPA Line (See Models Used On For Details)
$12.48
176.2 051-2025-02 051-2025-02 - 3/16 Vinyl 55" EPA Line
$12.48
176.3 067-0020-00 067-0020-00 - Carbon Canister
$62.40
176.4 072-8070-00 072-8070-00 - Tank Hose Clamp 3/16 (See Models Used On For Detail)
$2.99
176.5 072-8073-00 072-8073-00 - 3/16" Vinyl Hose Clamp
$2.99
188.1 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
188.3 081-4001-00 081-4001-00 - 2021-2024 Floor Mat W/ Reaper Tread
$53.49
188 079-3470-21 079-3470-21 - 2021 Maverick Floorboard Assembly
$159.99
217.0 250-1751-21 250-1751-21 2021-2024 ZT Suspension Arm Assy. Short Right
$109.99
217.1 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
217.2 014-3010-00 014-3010-00 - 5/8 Round Insert
$2.99
217.3 025-0003-00 025-0003-00 - Front Bearing Spacer
$14.04
218.0 250-1801-21 250-1801-21 - 2021-2022 ZT Suspension Arm Assembly Left
$106.99
218.4 250-1801-00 250-1801-00 - 2021-2022 ZT Suspension Component Left
$80.24
219.0 250-1851-21 250-1851-21 - 2021-2022 ZT Suspension Arm Assembly Long Right (54 & 60 Decks)
$106.99
