2022 ZT Elite - Lower Frame

2022 ZT Elite - Lower Frame

The 2022 ZT Elite Lower Frame is a vital component that supports the entire structure of your mower. If you need replacement parts for the lower frame, BadBoyMowerParts.com offers a full selection of high-quality Bad Boy Mower Parts. From frame brackets to support components, we carry everything you need for the 2022 ZT Elite’s lower frame assembly. Use our Bad Boy Mower Part diagrams to locate the right parts for your specific needs. We offer a comprehensive range of Bad Boy Lawn Mower Parts that are compatible with your lower frame and designed to last. Whether you're upgrading or replacing damaged parts, shopping Bad Boy Parts Online makes it easier than ever. Plus, you can take advantage of Free Shipping On Orders Over $100, ensuring that your parts arrive quickly and without extra charges. Maintain the integrity of your mower’s frame with the right parts from us.

Bad Boy Mower Parts Lookup

2022 ZT Elite - Lower Frame
  Position Number SKU Product Title Price
9 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
13 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
21 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
41 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
46 018-0026-00 018-0026-00 - 1-14 X 5 1/2 BOLT GR 8
$13.90
47 018-0028-00 018-0028-00 - 3/8x2 1/2" Hex Bolt
$4.39
50 018-1055-00 018-1055-00 - 1/2 x 3/4 Bolt
$2.99
53 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
63 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
64 018-5044-00 018-5044-00 - 3/8 x 1 Carriage Bolt
$2.99
82 019-2073-00 019-2073-00 -.390 ID Plastic Washer
$2.99
87 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
108 026-0019-01 026-0019-01 - Foot Pedal Assembly (See Models Used On For Details)
$93.69
111 028-0002-00 028-0002-00 - Actuator Bar-Front (See Models Used On For Detail)
$78.08
112 028-0003-00 028-0003-00 - Actuator Bar-Rear (See Models Used On For Detail)
$78.08
115 028-0070-00 028-0070-00 - Neutral Rod
$12.48
118 029-7040-00 029-7040-00 - EZT Front Bumper (See Models Used On For Detail)
$31.17
121 030-7040-00 030-7040-00 - 1/4 x 1 Hex Head Tek Screw
$2.99
125 031-0510-00 031-0510-00 - Actuator Linkage (See Models Used On For Details)
$46.84
126 032-9002-00 032-9002-00 - Isolator - Red Dot
$70.97
134 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
144 039-5944-01 039-5944-01 - Pump Idler Bracket Assy (See Models Used On For Details)
$62.46
155 044-2004-00 044-2004-00 - Bow Pin
$2.99
156 044-2008-00 044-2008-00 - Neutral Rod Clip
$2.99
164 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
183 070-5423-00 070-5423-00 - 2022 Suspension ZT Frame--Painted
$659.99
211 091-8002-00 091-8002-00 - Independently Articulating Front Susp. Arms Patent Decal
$5.49
217 250-1751-21 250-1751-21 2021-2024 ZT Suspension Arm Assy. Short Right
$109.99
218 250-1801-21 250-1801-21 - 2021-2022 ZT Suspension Arm Assembly Left
$106.99
219 250-1851-21 250-1851-21 - 2021-2022 ZT Suspension Arm Assembly Long Right (54 & 60 Decks)
$106.99
