2023 MZ Magnum - Seat & Fuel Tank - Detail

2023 MZ Magnum - Seat & Fuel Tank - Detail

Examine the 2023 MZ Magnum Seat & Fuel Tank - Detail to uncover the sophisticated design and practical functionality integrated into your mower. This detailed overview highlights the ergonomic seat coupled with a robust fuel tank, ensuring both comfort and operational efficiency. Clear diagrams and part details are available at Bad Boy Mower Part diagrams on BadBoyMowerParts.com, assisting with accurate installation and maintenance procedures. Complement your equipment with genuine Bad Boy Mower Parts and original Bad Boy Lawn Mower Parts, accessible through our streamlined Bad Boy Parts Online service. Enjoy Free Shipping On Orders Over $100 when purchasing these critical components. Built for long-lasting use and designed to withstand daily wear, the seat and fuel tank detail provide superior support and safety during operation. Ideal for performance upgrades and repairs, this integrated design ensures a secure, comfortable, and efficient riding experience for every mowing session. Enhanced comfort for every ride.

Bad Boy Mower Parts Lookup

2023 MZ Magnum - Seat & Fuel Tank - Detail
  Position Number SKU Product Title Price
119.0 028-0007-17 028-0007-17 - 2018-2022 MZ Magnum Deck Height Rod Assy.
$28.88
119.1 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
119.2 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
119.3 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
119.4 026-1100-00 026-1100-00 - 2017-Newer CAM Plate Use With Deck Adjuster (See Models Used On For Detail)
$15.55
119.5 028-0007-00 028-0007-00 - 2017-2024 MZ Deck Height Dial Rod
$31.17
137.0 034-8045-03 034-8045-03 - Seat Spring Assembly (See Models Used On For Detail)
$32.09
137.1 013-0017-00 013-0017-00 - 3/8-16 Half Jam Nut
$2.99
137.2 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
137.3 018-3000-00 018-3000-00 - 3/8-16 X 2 Hex Bolts Zinc
$2.99
137.5 034-8045-00 034-8045-00 - Seat Spring
$20.49
138.0 034-8045-22 034-8045-22 - 2022 Mav/HD seat spring assembly with st
$32.09
138.6 064-8083-00 064-8083-00 Seat Strap w/Buckles
$24.60
162.1 051-2014-01 051-2014-01 - 37" 1/4 Fuel Line (No Clamp)
$19.25
162.2 072-8069-00 072-8069-00 - 1/4 Fuel Line Clamp
$2.99
162.3 067-6057-00 067-6057-00 2 Way Fuel Shut-Off Valve
$16.04
162.4.2 051-8067-00 051-8067-00 - 1/4 Fuel Line Hose (Priced by the Foot)
$6.41
181.0 067-2090-50 067-2090-50 - Left Side Fuel Tank 2017-2024 MZ & MZ Magnum
$248.99
181.1 066-8083-00 066-8083-00 - 3.5" Tethered Fuel Cap
$23.53
181.4 067-6080-00 067-6080-00 - Grommet for ZT Elite Fuel Line Pickup Tube
$8.01
181.5 067-6070-00 067-6070-00 - Rollover Valve and Grommet New
$24.60
181.6 067-4090-00 067-4090-00 - Fuel Gauge (See Models Used On For Details)
$46.00
181.7 067-0011-00 067-0011-00 - Fuel Line Pickup Tube
$23.41
187.0 071-1000-22 071-1000-22 - 2022 - 2024 Magnum Seat
$429.99
