2023 Maverick - 48" Deck Assembly

2023 Maverick - 48" Deck Assembly

The 2023 Maverick 48" Deck Assembly is designed for precision cutting and long-lasting durability. At BadBoyMowerParts.com, we provide high-quality Bad Boy Mower Parts to keep your deck in peak condition. Whether you need spindles, belts, or blades, our Bad Boy Mower Part diagrams make it easy to find exactly what you need. A well-maintained deck ensures a clean, professional cut every time, and our Bad Boy Lawn Mower Parts selection guarantees top performance. Shopping for Bad Boy Parts Online is hassle-free with our organized categories and part lookup tools. Plus, with Free Shipping On Orders Over $100, you can keep your deck in top shape without extra costs. Trust BadBoyMowerParts.com for all your 48-inch deck assembly needs, providing you with reliable parts that enhance your mowing experience.

Bad Boy Mower Parts Lookup

2023 Maverick - 48" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6006-00 088-6006-00 - Advanced Chute System For Select 42", 48", 50", 52" Mowers & select 54", 2022 - 2024 Maverick HD 42", Will Not Fit MZ
$249.00
1B 210-0248-50 210-0248-50 - 2017- 2025 48" Mulch Kit w/Blades (Not for Avenger and MZ)
$318.45
1C 092-4001-23 092-4001-23 Top Discharge Bagger (2017-2025 48" Maverick & Maverick HD)
$2399.99
1 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
8 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
9 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
10 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
13 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
16 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
22 014-4025-00 014-4025-00 - Extra Small Pulley Cover - Right (See Models Used On For Details)
$17.86
23 014-4026-00 014-4026-00 - Extra Small Pulley Cover - Left
$17.86
35 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
41 018-0075-00 018-0075-00 - 3/8-16 x 1-3/4 Hex C/S () ZC
$3.29
45 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
49 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
53 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
57 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
58 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
63 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
64 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
65 018-6054-00 018-6054-00 - 1/2-13 X 3-1/2 Hex Bolts
$2.99
66 018-7060-00 018-7060-00 - 3/8-16 x 5 1/2 Hex Bolt -
$2.99
71 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
74 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
76 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
77 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
81 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
84 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
92 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
93 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
95 026-0024-00 026-0024-00 - 42 & 48 Deck Spindle Support Plate
$14.19
96 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
107 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
120 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
121 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
124 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
126 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
132 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$199.99
134 038-5350-00 038-5350-00 - 48"/50" High Lift Fusion Blade
$22.99
135 038-5000-00 038-5000-00 - 48"/50" Gator Mulching Blade
$22.99
140 039-2127-17 039-2127-17 - Deck Hanger Assy. (See Models Used On For Details)
$15.60
142 039-6945-17 039-6945-17 - Deck Idler Assembly
$70.97
143 041-1470-00 041-1470-00 - B147 Deck Belt (See Models Used On For Details)
$87.39
148 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
153 048-6000-00 048-6000-00 - Maverick/Compact Outlaw/Revolt Toplink
$80.24
162 060-2312-00 060-2312-00 - 2023 48" ZT/Maverick/HD Deck--Painted
$999.99
194 091-0903-18 091-0903-18 - 48" Deck Decal (See Models Used On For Details)
$8.01
197 091-3012-00 091-3012-00 - Danger Decal-Spindle/Discharge
$2.99
200 091-3309-00 091-3309-00 - Deck Belt Route Decal
$6.41
204 091-8001-00 091-8001-00 - Impact Absorption Patent Decal
$2.99
207 210-6005-48 210-6005-48 - Chute Assembly (See Models Used On For Detail)
$169.99
