2023 Maverick - Engine - Briggs CXI

2023 Maverick - Engine - Briggs CXI

The 2023 Maverick Engine - Briggs CXI is built for power, efficiency, and reliability. When it comes to maintenance, BadBoyMowerParts.com has the Bad Boy Mower Parts you need to keep this engine running strong. Our Bad Boy Mower Part diagrams help you quickly locate spark plugs, filters, belts, and more. A properly maintained engine ensures maximum performance, and our Bad Boy Lawn Mower Parts selection makes upkeep easy. With Bad Boy Parts Online, you can browse and order with confidence, knowing you’re getting quality components. Plus, enjoy Free Shipping On Orders Over $100, making engine maintenance more affordable. Trust BadBoyMowerParts.com for all your Briggs CXI engine parts, ensuring your 2023 Maverick runs smoothly for years to come.

Bad Boy Mower Parts Lookup

2023 Maverick - Engine - Briggs CXI
  Position Number SKU Product Title Price
1A 063-2000-04 063-2000-04 - Briggs 30hp & CXI Engine Service Kit
$92.93
1C 055-8020-00 055-8020-00 - Throttle Cable-53" (See Models Used On For Details)
$38.97
2B 054-8017-00 054-8017-00 - 62" Choke Cable (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$25.80
14 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
17 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
30 015-0057-00 015-0057-00 - 2017-2024 Exhaust 810 Vanguard
$169.99
31.1 015-2709-00 015-2709-00 - Exhaust Gasket (See Models Used On For Detail)
$8.01
31.2 015-8000-00 015-8000-00 - Spark Plug (RC12YC or Equivalent)
$13.90
31.3 063-1000-00 063-1000-00 - Pre-Cleaner for 063-3003-00
$12.83
31.4 063-1005-00 063-1005-00 - Air Filter for Vanguard CXI Engine (obsolete)
use part #063-3003-00
$44.93
31.5 063-6000-00 063-6000-00 - Universal Inline Fuel Filter
$14.19
31.6 063-8018-00 063-8018-00 - Oil Filter
$21.39
31 015-0511-00 015-0511-00 - Vangaurd 27hp CXI with Out Oil Filter
$3099.99
36 018-0017-00 018-0017-00 - Vanguard Exhaust Torx Bolt
$5.82
43 018-1075-00 018-1075-00 - 3/8 x 1 1/8 Engine Mounting Bolt
$2.99
61 018-5350-00 018-5350-00 - 5/16-18 X 5-1/2 Hex Bolt
$2.99
62 018-5450-21 018-5450-21 - 7/16-20 x 1.5" Hex bolt GR 8 w/ Patch
$2.99
67 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
69 019-0010-00 019-0010-00 - 7/16 x 1-5/8 OD x 1/4 Thick Custom AISI 1018 CF ZC
$5.93
82 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
107 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
110 030-7044-00 030-7044-00 - 5/16-18 x HWH unslot (F) tcs zinc
$2.99
119 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley - Extended Shaft (See Models Used On For Details)
$42.58
146 041-7400-00 041-7400-00 - Pump Belt for Maverick and Maverick HD
$64.19
147 042-5020-00 042-5020-00 - 1/4 X 2 Square Key Stock
$2.99
150.1 043-8930-00 043-8930-00 2023 - Rubber Battery Hold Down Strap
$21.39
150.2 043-8931-00 043-8931-00 - 2023 Battery Tray Only
$20.32
165 064-0030-00 064-0030-00 - 24 inch Black Battery Cable
$18.72
168 064-5300-00 064-5300-00 - 24" Red Battery Cable
$21.85
169 064-5301-00 064-5301-00 - 12" Red Battery Cable
$17.16
175 070-0056-00 070-0056-00 - PTO Clutch (See Models Used On For Details)
$364.84
176 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
206 108-0001-00 108-0001-00 - Solenoid
$29.41
