2023 Maverick HD - 48" Deck Assembly

2023 Maverick HD - 48" Deck Assembly

Maintaining the 2023 Maverick HD 48" Deck Assembly ensures a professional-quality cut and extended mower life. Access Bad Boy Mower Part diagrams to identify and replace necessary components with ease. At BadBoyMowerParts.com, we carry a complete range of Bad Boy Mower Parts, including spindles, blades, pulleys, and belts. Keeping your deck in optimal shape is simple with our high-quality Bad Boy Lawn Mower Parts, all designed to match factory specifications. Shopping for Bad Boy Parts Online allows you to quickly find and order what you need without the hassle of searching multiple stores. Plus, we offer Free Shipping On Orders Over $100, making it more affordable to maintain your mower. Ensure your 2023 Maverick HD 48" Deck Assembly operates at peak performance—shop now and get back to mowing with confidence!

Bad Boy Mower Parts Lookup

2023 Maverick HD - 48" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6006-00 088-6006-00 - Advanced Chute System For Select 42", 48", 50", 52" Mowers & select 54", 2022 - 2024 Maverick HD 42", Will Not Fit MZ
$249.00
1B 210-0248-50 210-0248-50 - 2017- 2025 48" Mulch Kit w/Blades (Not for Avenger and MZ)
$318.45
1C 092-4001-23 092-4001-23 Top Discharge Bagger (2017-2025 48" Maverick & Maverick HD)
$2399.99
2 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
9 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
10 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
11 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
14 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
16 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
17 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
24 014-4025-00 014-4025-00 - Extra Small Pulley Cover - Right (See Models Used On For Details)
$17.86
25 014-4026-00 014-4026-00 - Extra Small Pulley Cover - Left
$17.86
41 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
46 018-0075-00 018-0075-00 - 3/8-16 x 1-3/4 Hex C/S () ZC
$3.29
50 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
54 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
59 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
60 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
64 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
66 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
70 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
71 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
72 018-6054-00 018-6054-00 - 1/2-13 X 3-1/2 Hex Bolts
$2.99
73 018-7060-00 018-7060-00 - 3/8-16 x 5 1/2 Hex Bolt -
$2.99
78 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
81 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
83 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
84 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
89 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
92 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
102 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
103 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
105 026-0024-00 026-0024-00 - 42 & 48 Deck Spindle Support Plate
$14.19
106 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
108 026-0307-00 026-0307-00 - 2023 4' & 5' Striping Kit Plate-Painted
$10.99
119 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
132 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
133 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
137 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
139 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
145 037-4000-00 037-4000-00 - Commercial Spindle Assembly (See Models Used On For Details)
$291.91
148 038-5350-00 038-5350-00 - 48"/50" High Lift Fusion Blade
$22.99
149 038-5000-00 038-5000-00 - 48"/50" Gator Mulching Blade
$22.99
154 039-2127-17 039-2127-17 - Deck Hanger Assy. (See Models Used On For Details)
$15.60
156 039-6945-17 039-6945-17 - Deck Idler Assembly
$70.97
157 041-1470-00 041-1470-00 - B147 Deck Belt (See Models Used On For Details)
$87.39
163 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
168 048-6000-00 048-6000-00 - Maverick/Compact Outlaw/Revolt Toplink
$80.24
178 060-2312-00 060-2312-00 - 2023 48" ZT/Maverick/HD Deck--Painted
$999.99
202 084-5006-00 084-5006-00 - 2023 ZT Stripe Kit Rubber
$56.77
219 091-0903-18 091-0903-18 - 48" Deck Decal (See Models Used On For Details)
$8.01
224 091-3012-00 091-3012-00 - Danger Decal-Spindle/Discharge
$2.99
227 091-3309-00 091-3309-00 - Deck Belt Route Decal
$6.41
233 091-8001-00 091-8001-00 - Impact Absorption Patent Decal
$2.99
236 210-6005-48 210-6005-48 - Chute Assembly (See Models Used On For Detail)
$169.99
