2023 Maverick HD - 60" Deck Assembly

2023 Maverick HD - 60" Deck Assembly

The 2023 Maverick HD 60" Deck Assembly is engineered for precision and durability, making it an excellent choice for larger mowing areas. To ensure your deck remains in top shape, utilizing Bad Boy Mower Part diagrams is essential for locating and installing replacement components. At BadBoyMowerParts.com, we stock a comprehensive inventory of Bad Boy Mower Parts, including belts, blades, and spindle assemblies. Our high-quality Bad Boy Lawn Mower Parts guarantee long-lasting performance and a perfect fit for your machine. When you shop for Bad Boy Parts Online, you gain access to our extensive selection from the comfort of your home. Additionally, take advantage of Free Shipping On Orders Over $100, making it easier and more cost-effective to maintain your 2023 Maverick HD 60" Deck Assembly. Don't wait—order now and keep your mower running at its best!

Bad Boy Mower Parts Lookup

2023 Maverick HD - 60" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1B 210-0260-50 210-0260-50 - 2017-2025 60" Mulch Kit w/Blades (Not for MZ or Avenger)
$318.45
1C 092-4006-23 092-4006-23 Top Discharge Bagger (2017-2025 60" ZT Elite, Maverick & Maverick HD)
$2399.99
2 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
9 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
10 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
11 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
14 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
16 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
17 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
26 014-5020-00 014-5020-00 - 2021-2022 Maverick 54"/60" RH Pulley Cover
$28.39
27 014-5021-00 014-5021-00 - 2021-2022 Maverick 54"/60" LH Pulley Cover
$28.39
41 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
46 018-0075-00 018-0075-00 - 3/8-16 x 1-3/4 Hex C/S () ZC
$3.29
50 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
54 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
59 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
60 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
64 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
66 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
70 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
71 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
72 018-6054-00 018-6054-00 - 1/2-13 X 3-1/2 Hex Bolts
$2.99
73 018-7060-00 018-7060-00 - 3/8-16 x 5 1/2 Hex Bolt -
$2.99
78 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
81 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
83 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
84 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
89 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
92 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
102 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
103 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
106 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
108 026-0307-00 026-0307-00 - 2023 4' & 5' Striping Kit Plate-Painted
$10.99
119 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
134 033-6004-00 033-6004-00 - 6 1/4" Spindle Deck Pulley (without set screw) (See Models Used On For Detail)
$35.48
137 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
139 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
145 037-4000-00 037-4000-00 - Commercial Spindle Assembly (See Models Used On For Details)
$291.91
149 038-6060-00 038-6060-00 - 60" High Lift Fusion Blade & 2023-2025 Revolt SD 42"
$22.99
150 038-6003-00 038-6003-00 - 60" Gator Mulching Blade & 2023-2025 Revolt SD 42"
$22.99
154 039-2127-17 039-2127-17 - Deck Hanger Assy. (See Models Used On For Details)
$15.60
156 039-6945-17 039-6945-17 - Deck Idler Assembly
$70.97
159 041-1650-00 041-1650-00 - B165 Deck Belt (See Models Used On For More Details, Not For 54" ZT/CZT/Maverick)
$90.94
163 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
168 048-6000-00 048-6000-00 - Maverick/Compact Outlaw/Revolt Toplink
$80.24
180 060-2316-00 060-2316-00 - 2023 60" ZT/Maverick/HD Deck-Painted
$1099.99
202 084-5006-00 084-5006-00 - 2023 ZT Stripe Kit Rubber
$56.77
221 091-0905-18 091-0905-18 - 2018-2023 60" Deck Decal
$6.41
224 091-3012-00 091-3012-00 - Danger Decal-Spindle/Discharge
$2.99
227 091-3309-00 091-3309-00 - Deck Belt Route Decal
$6.41
233 091-8001-00 091-8001-00 - Impact Absorption Patent Decal
$2.99
237 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
