2023 Maverick HD - Drive Arm Assembly

2023 Maverick HD - Drive Arm Assembly

The 2023 Maverick HD Drive Arm Assembly is responsible for the smooth and efficient movement of your mower. When wear and tear take a toll, referring to Bad Boy Mower Part diagrams can help you quickly identify the right replacement. At BadBoyMowerParts.com, we carry a full range of Bad Boy Mower Parts, including drive arm assemblies engineered for durability and precision. Our Bad Boy Lawn Mower Parts ensure that your mower remains responsive and efficient, no matter the terrain. Shopping for Bad Boy Parts Online makes finding and ordering the correct parts easy, saving you time and effort. Plus, enjoy Free Shipping On Orders Over $100, making it cost-effective to maintain your 2023 Maverick HD Drive Arm Assembly. Order now and keep your mower performing at its best!

Bad Boy Mower Parts Lookup

2023 Maverick HD - Drive Arm Assembly
  Position Number SKU Product Title Price
8 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
12 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
13 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
17 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
20 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
49 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
55 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
61 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
62 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
79 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
80 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
87 019-8027-00 019-8027-00 -.515 ID Plastic Shoulder Washer
$2.99
91 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
114 028-0049-00 028-0049-00 - 2021 Maverick Steering Actuator Rod
$21.39
123 031-0053-21 031-0053-21 - 2021-2022 Maverick Drive Arm Actuator RH Assembly
$42.79
124 031-0054-21 031-0054-21 - 2021-2022 Maverick Drive Arm Actuator LH Assembly
$42.79
126 031-9000-18 031-9000-18 - Left Adjustable Steering Arm (See Models Used On For Details)
$144.50
127 031-9050-18 031-9050-18 - 2017 - 2022 Right Adjustable Steering Arm Black
$144.50
140 034-8025-00 034-8025-00 - Drive Lever Housing Spring
$4.07
143 035-5450-00 035-5450-00 - Right Steering Push Rod (See Models Used On For Details)
$33.95
144 035-5451-00 035-5451-00 - Left Steering Push Rod (See Models Used On For Details)
$42.58
197 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
211 087-0001-00 087-0001-00 - Steering Damper (See Models Used On For Details)
$62.40
