2023 Renegade - Diesel - Hydraulic Pump & Idlers

2023 Renegade - Diesel - Hydraulic Pump & Idlers

The 2023 Renegade - Diesel Hydraulic Pump & Idlers are integral to the performance of the mower's hydraulic system, which powers key components such as the lift system and transmission. The hydraulic pump pressurizes the fluid, while the idlers help manage the flow and tension. At BadBoyMowerParts.com, we carry a wide range of Bad Boy Mower Parts for the 2023 Renegade - Diesel Hydraulic Pump & Idlers. Our Bad Boy Mower Part diagrams make it easy to identify and find the right parts for repairs. We offer Bad Boy Lawn Mower Parts that are built for performance and durability. Additionally, enjoy the convenience of Free Shipping On Orders Over $100, making it easier to keep your mower’s hydraulic system in top condition.

Bad Boy Mower Parts Lookup

2023 Renegade - Diesel - Hydraulic Pump & Idlers
  Position Number SKU Product Title Price
191.0 039-6950-94 039-6950-94 - 2020 and newer Diesel Pump Tensioner Assembly LH
$85.17
191.1 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
191.3 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
191.4 018-0022-00 018-0022-00 - 1/2-13 x 2 Grade 8 Hex Bolt
$2.99
191.5 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
191.6 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
191.7 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
191.8 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
191.9 039-6950-00 039-6950-00 - Gas Idler Plate Weldment Renegade
$29.80
192.0 039-6950-95 039-6950-95 - 2020 and newer Diesel Pump Tensioner Assembly RH
$85.17
192.2 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
192.5 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
205.0 050-3001-00 050-3001-00 - Rogue/Renegade Left Pump 16cc Hydro-Gear# PR-2KCC-GB1C-XXXX (See Models Used On For Details)
$699.99
205.1 014-5600-00 014-5600-00 - Fan Guard 6.5" - Fits Wheel Motor Pumps
$39.81
205.2 015-9999-00 015-9999-00 - Hydro Fan - Fits Hydraulic Pumps
$28.88
206.0 050-3003-00 050-3003-00 - 2019-2024 Renegade Right Pump 16cc Hydro-Gear # PR-2HCC-GA1C-XXXX
$649.99
