2023 Revolt - Front End

2023 Revolt - Front End

The 2023 Revolt Front End is a critical part of your mower’s overall performance, providing stability and control. If you need to replace or repair your front end, Bad Boy Mower Part diagrams will guide you in finding the right parts. At BadBoyMowerParts.com, we carry a variety of Bad Boy Mower Parts designed specifically for the front end of the 2023 Revolt, including wheels, suspension components, and steering linkages. With our Bad Boy Lawn Mower Parts, you can easily maintain the stability and performance of your mower. Shopping for Bad Boy Parts Online is convenient, and with Free Shipping On Orders Over $100, you’ll have the parts you need delivered straight to you.

Bad Boy Mower Parts Lookup

2023 Revolt - Front End
  Position Number SKU Product Title Price
1 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
6 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
11 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
20 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
24 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
26 014-2025-00 014-2025-00 - Caster Bearing Cover (See Models Used On For Details)
$2.99
49 018-0040-00 018-0040-00 - 1/2-13 x 8 1/2 Gr5 Hex Bolt
$7.18
50 018-0044-00 018-0044-00 - 3/8 x 2 1/2 Carriage Bolt
$2.99
57 018-0072-00 018-0072-00 - 3/8-16 x 3 Carriage Bolt Zinc GR5
$2.99
122 023-1010-00 023-1010-00 - Front Fork 2019-2022 Revolt, 2021-2022 Maverick
$145.95
126 025-0003-00 025-0003-00 - Front Bearing Spacer
$14.04
133 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
134 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
138 026-0049-00 026-0049-00 - 2019-2022 Revolt Front Bumper Plate
$26.74
143 026-0084-00 026-0084-00 - Exhaust Shield Plate 2019-2022 Revolt
$13.90
144 026-0085-00 026-0085-00 - Exhaust Backer Plate
$16.04
161 029-7040-00 029-7040-00 - EZT Front Bumper (See Models Used On For Detail)
$31.17
164 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
246 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
266 070-5221-20 070-5221-20 - 2020 36" Revolt Frame
$1299.99
368 070-9062-00 070-9062-00 - 61" Stand On Front End--Orange
$229.99
370.1 022-3088-00 022-3088-00 - 13x6.50-6 Black No Flat Assy 2015-2019 Outlaw, 2022 - 2025 Maverick, Maverick HD, Rebel (Will Not Work On Renegade & Rogue)
$145.99
370.2 022-7010-00 022-7010-00 - 1 3/4" Bearing - Large Bore Front Wheel
$20.32
