2023 Revolt - Podium Assembly - Detail

2023 Revolt - Podium Assembly - Detail

The 2023 Revolt Podium Assembly - Detail is an important structural component of your mower that ensures stability and ease of operation. If you need to replace or repair this part, Bad Boy Mower Part diagrams provide a helpful visual breakdown of the entire assembly. At BadBoyMowerParts.com, we offer a variety of Bad Boy Mower Parts for the podium assembly, including frames, mounting hardware, and support brackets. Our Bad Boy Lawn Mower Parts are designed to fit your mower precisely, ensuring a secure and durable setup. Shopping for Bad Boy Parts Online is simple, and with Free Shipping On Orders Over $100, maintaining your mower becomes both affordable and convenient.

Bad Boy Mower Parts Lookup

2023 Revolt - Podium Assembly - Detail
  Position Number SKU Product Title Price
25 013-9005-00 013-9005-00 - 5/16-18 Nylock Jam Nut
$2.99
63 018-2006-00 018-2006-00 - 5/16-18 X 1-1/4 Hex Bolt
$2.99
131 025-2001-00 025-2001-00 - ACS Spacer 3/4x3/8x1/4
$15.60
192 035-0006-19 035-0006-19 - Push-Rod Assembly
$46.84
431.5 069-2013-00 069-2013-00 - 2019 Revolt Brake Handle
$109.99
431.29 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
431.30 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
431.61 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
432.2 031-0026-00 031-0026-00 - Front Control Arm Stop 2019-2022 Revolt
$61.09
432.5 089-1000-00 089-1000-00 - Oil Light
$12.63
432.7 083-4013-00 083-4013-00 - Tachometer-N211-0100-1003
$74.89
432.8 077-8076-00 077-8076-00 - 3-Position Ignition Switch (key not included)
$21.39
432.9 077-2076-00 077-2076-00 - USB Port
$46.84
432.11 071-6005-00 071-6005-00 - Revolt Cup Holder (See Models Used On For Details)
$22.71
432.12 069-2014-00 069-2014-00 - 2019-2022 Cushioned Grip (See Models Used On For Details)
$8.01
432.13 069-0002-00 069-0002-00 - Retractable Spring Plunger Black Steel 5/8-11
$84.52
432.16 064-3000-00 064-3000-00 - 44" Brake Cable
$31.22
432.17 056-8058-00 056-8058-00 - PTO Engager-Switch for Blades
$34.29
432.18 055-2012-00 055-2012-00 - Universal Throttle/Brake Lever (Knob Not Included)
$25.54
432.20 031-0091-00 031-0091-00 - Drive Pivot Bar 2020-2022 Revolt
$35.48
432.21 013-0001-00 013-0001-00 - 8-32 Hex Nut
$2.99
432.23 069-7000-00 069-7000-00 - Rubber Brake Grip
$6.41
432.24 055-2013-00 055-2013-00 - Throttle/Brake Head Ball
$12.48
432.25 034-1025-00 034-1025-00 - Brake Spring (See Models Used On For Detail)
$12.48
432.26 042-9000-00 042-9000-00 - Ignition Key
$4.06
432.29 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
432.30 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
432.32 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
432.33 018-6049-00 018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc
$2.99
432.34 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
432.35 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
432.36 018-5020-00 018-5020-00 - 5/16-18 X 1-1/2 Carriage Bolt
$2.99
432.37 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
432.38 018-0056-00 018-0056-00 - 5/16x6 Carriage Bolt
$2.99
432.39 018-0024-00 018-0024-00 - M6-1.0 X 16MM HEX BOLT
$2.99
432.40 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
432.42 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
432.43 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
432.44 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
432.45 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
432.47 026-0270-00 026-0270-00 - 2023 Podium Panel Right--Orange
$42.79
432.53 026-0264-00 026-0264-00 - 2023-2025 Stand on Battery Hold Down
$16.04
432.57 026-0280-00 026-0280-00 - 2023 Podium Panel Left--Orange
$42.79
440 083-4015-00 083-4015-00 Tach For FX1000 EFI & EVO 781 & 820
$64.19
