2023 Revolt - Rear Wheels

2023 Revolt - Rear Wheels

The 2023 Revolt Rear Wheels play a critical role in providing stability and maneuverability for your mower. Over time, the rear wheels may wear out or become damaged. When it’s time to replace them, Bad Boy Mower Part diagrams make it easy to identify the exact parts you need. At BadBoyMowerParts.com, we offer a wide range of Bad Boy Mower Parts for the rear wheels, including tires, hubs, and bearings. Our Bad Boy Lawn Mower Parts are built for durability and precision, ensuring that your mower continues to perform at its best. Shopping for Bad Boy Parts Online is quick and easy, and with Free Shipping On Orders Over $100, you can have your parts delivered directly to your door without the extra shipping costs.

Bad Boy Mower Parts Lookup

2023 Revolt - Rear Wheels
  Position Number SKU Product Title Price
1A 022-4041-00 022-4041-00 - 36" Revolt Reaper Wheel Assy. 21x7x10
$195.99
1B 022-4200-00 022-4200-00 - 23x11-12 Reaper Tire/Wheel Assembly (See Models Used On For Details)
$320.99
1C 022-4040-00 022-4040-00 - 23x9-12 Reaper Turf (See Models Used On for Details)
$329.99
1D 035-0006-19 035-0006-19 - Push-Rod Assembly
$46.84
119.1 022-3011-00 022-3011-00 - 12x7" Black Wheel-48" EZT Only
$109.99
119.2 022-4035-00 022-4035-00 - 23x9 - 12 Reaper Turf Tire Only
$201.99
121.1 022-4070-00 022-4070-00 - Black Wheel 12x8.5 (See Models Used On for Detail)
$141.99
121.2 022-4195-00 022-4195-00 - 23x11-12 Reaper Turf Tire
$255.99
192.1 013-6050-00 013-6050-00 - 5/16 LH Nut For Push Rods
$4.39
192.2 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
192.3 031-0092-00 031-0092-00 - 2019 Revolt Drive Arm
$21.39
192.5 048-3000-00 048-3000-00 - Spherical Rod End (See Models Used On For Details)
$14.19
192.6 048-3002-00 048-3002-00 - Spherical Rod End - LH Thread (See Models Used On For Details)
$32.09
