Position Number |
SKU |
Product Title |
Price |
|
|
108.1 |
013-6051-00 |
013-6051-00 - 3/8-24 Hex Jam Nuts Zinc |
$2.99
|
|
|
108.2 |
019-5029-00 |
019-5029-00 - 3/8 USS Flat Washer Zinc |
$2.99
|
|
|
108.3 |
019-5037-00 |
019-5037-00 - 3/8 Lockwasher Zinc |
$2.99
|
|
|
108.4 |
026-1100-00 |
026-1100-00 - 2017-2024 CAM Plate Use With Deck Adjuster (See Models Used On For Detail) |
$15.55
|
|
|
108.5 |
028-0014-00 |
028-0014-00 - Deck Height Dial Rod (See Models Used For Detail) |
$31.17
|
|
|
108 |
028-0070-17 |
028-0070-17 - Deck Height Bar Assy. (See Models Used On for Details) |
$29.66
|
|
|
122.1 |
013-0017-00 |
013-0017-00 - 3/8-16 Half Jam Nut |
$2.99
|
|
|
122.2 |
013-5201-00 |
013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations |
$2.99
|
|
|
122.3 |
018-3000-00 |
018-3000-00 - 3/8-16 X 2 GR 5 Hex Bolts Zinc |
$2.99
|
|
|
122.5 |
034-8045-00 |
034-8045-00 - Seat Spring |
$20.49
|
|
|
122 |
034-8045-03 |
034-8045-03 - Seat Spring Assembly (See Models Used On For Detail) |
$32.09
|
|
|
123.6 |
064-8083-00 |
064-8083-00 Seat Strap w/Buckles |
$24.60
|
|
|
143.1 |
051-8067-00 |
051-8067-00 - 1/4 Fuel Line Hose PRICED/FOOT |
$6.41
|
|
|
143.2 |
072-8069-00 |
072-8069-00 - 1/4 Fuel Line Clamp |
$2.99
|
|
|
143.4 |
067-6057-00 |
067-6057-00 2 Way Fuel Shut-Off Valve |
$16.04
|
|
|
144.1 |
051-2014-01 |
051-2014-01 - 37" 1/4 Fuel Line (No Clamp) |
$19.25
|
|
|
158.1 |
066-8083-00 |
066-8083-00 - 3.5" Tethered Fuel Cap |
$21.23
|
|
|
158.2 |
067-0011-00 |
067-0011-00 - Fuel Line Pickup Tube (See Models Used On For Detail) |
$23.41
|
|
|
158.3 |
067-4090-00 |
067-4090-00 - Fuel Gauge (See Models Used On For Details) |
$46.00
|
|
|
158.4 |
067-6070-00 |
067-6070-00 - Rollover Valve and Grommet New |
$24.60
|
|
|
158.5 |
067-6080-00 |
067-6080-00 - Grommet for ZT Elite Fuel LinePickup Tube |
$8.01
|
|
|
158 |
067-2060-50 |
067-2060-50 - Left Fuel Tank (See Models Used On For Details) |
$310.99
|
|
|
161.1 |
013-0012-00 |
013-0012-00 - 3/8-16 Centerlock Half Nut |
$3.29
|
|
|
161.2 |
013-8042-00 |
013-8042-00 - 5/16-18 Nylon Insert Cap Locknut Zinc (Black Cap) |
$2.99
|
|
|
161.3 |
013-8049-00 |
013-8049-00 - 5/16-18 Nylon Flange Nut |
$2.99
|
|
|
161.4 |
013-9002-00 |
013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations |
$2.99
|
|
|
161.5 |
018-5043-00 |
018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt |
$2.99
|
|
|
161.6 |
018-8065-00 |
018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc |
$2.99
|
|
|
161.8 |
025-0001-00 |
025-0001-00 - 2015-2024 Brake Lever Spacer |
$8.01
|
|
|
161.9 |
032-5053-00 |
032-5053-00 - Bronze Bushing SF-1220-8 2013 & UP CZT/ZT Brake Bushing |
$2.99
|
|
|
161.10 |
039-0170-00 |
039-0170-00 - Brake Cable Extension Plate |
$10.99
|
|
|
161.11 |
039-0171-00 |
039-0171-00 - Brake Load Balancer Weldment |
$10.99
|
|
|
161.12.1 |
069-3000-00 |
069-3000-00 - Switch Relocation Brake Handle |
No Longer Available
Obsolete.
|
|
|
161.12.2 |
069-3010-00 |
069-3010-00 - Brake Handle Rubber |
$18.45
|
|
|
161.12 |
069-1051-00 |
069-1051-00 - Load Balanced Brake Handle With Grip |
$64.19
|
|
|
161 |
069-1051-21 |
069-1051-21 - Load Balanced Brake Handle Assembly |
$70.97
|
|
|
165.1 |
071-1004-00 |
071-1004-00 - Switch Only Delta for 071-1000-22/071-2100-22 |
No Longer Available
Obsolete.
|
|
|
165.2 |
071-2108-00 |
071-2108-00 - Bad Boy SK130 Avenger Cover for 071-2100-22 |
$128.39
|
|
|
165.3 |
071-2110-00 |
071-2110-00 - SK130 Water Proofing Protection for 071-2100-22 |
No Longer Available
Obsolete.
|
|
|
165 |
071-2100-22 |
071-2100-22 - 2022 - 2024 Avenger Seat |
$599.99
|
|
