2023 ZT Avenger - Upper Frame

2023 ZT Avenger - Upper Frame

The upper frame of your 2023 ZT Avenger plays a critical role in supporting various mower components, ensuring overall durability and strength. At BadBoyMowerParts.com, we offer a wide selection of Bad Boy Mower Parts, including high-quality replacement upper frame parts for your mower. Our easy-to-use Bad Boy Mower Part diagrams allow you to quickly locate the exact part you need, whether you're replacing the entire upper frame or specific components. We carry a variety of Bad Boy Lawn Mower Parts that are engineered for strength and long-lasting performance. By shopping Bad Boy Parts Online, you can conveniently order the parts you need and have them delivered to your door. Plus, with Free Shipping On Orders Over $100, you can save on your mower maintenance costs. Ensure your 2023 ZT Avenger stays strong and reliable with durable upper frame parts from us.

Bad Boy Mower Parts Lookup

2023 ZT Avenger - Upper Frame
  Position Number SKU Product Title Price
6 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
13 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
16 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
20 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
26 014-8047-00 014-8047-00 - Rubber Cap Cover
$2.99
44 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
46 018-2006-00 018-2006-00 - 5/16-18 X 1-1/4 Hex Bolt
$2.99
70 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
71 018-8066-00 018-8066-00 - 5/16 x 7/8 Carriage Bolt
$2.99
81 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
82 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
84 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
86 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
102 026-2022-00 026-2022-00 - Seat Plate (See Models Used On For Detail)
$119.99
109 029-4011-00 029-4011-00 2023 Floorboard Rubber Bumpers
$2.99
122 034-8045-03 034-8045-03 - Seat Spring Assembly (See Models Used On For Detail)
$32.09
123 034-8045-22 034-8045-22 - 2022 Mav/HD seat spring assembly with st
$32.09
153 064-3050-21 064-3050-21 - 2021-2025 Load Balanced Brake Cable 1
$56.77
154 064-3051-21 064-3051-21 - 2021-2025 Load Balanced Brake Cable 2
$56.77
161 069-1051-21 069-1051-21 - Load Balanced Brake Handle Assembly
$70.97
165 071-2100-22 071-2100-22 - 2022-2024 Avenger & 2025 MZ Magnum Seat
$559.99
166 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
175 091-0214-00 091-0214-00 - LH/RH Steering Control Decal (See Models Used On For Details)
$9.34
176 091-0339-18 091-0339-18 - Brake Decal (See Models Used On For Details)
$11.76
181 091-3150-00 091-3150-00 - Outlaw Warning Decal (See Models Used On For Details)
$10.91
184 091-4063-00 091-4063-00 - Flying Bulldog Front Bumper Decal
$12.83
