2023 ZT Elite - Drive Arms

2023 ZT Elite - Drive Arms

The drive arms in your 2023 ZT Elite mower are key components that transfer the power from your engine to the wheels. At BadBoyMowerParts.com, we offer a wide selection of Bad Boy Mower Parts, including high-quality drive arms that are designed to keep your mower running smoothly. Whether you need to replace a broken drive arm or want to ensure optimal performance, we have the parts you need. Our Bad Boy Mower Part diagrams make it simple to identify the exact drive arm for your mower. We only carry durable Bad Boy Lawn Mower Parts that offer long-lasting performance. Shopping Bad Boy Parts Online is fast, and we offer Free Shipping On Orders Over $100 to make your purchases even more affordable. Get your 2023 ZT Elite back to peak performance with premium drive arms from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2023 ZT Elite - Drive Arms
  Position Number SKU Product Title Price
1A 031-9060-18 031-9060-18 - Adjustable Steering Arm Kit
$178.99
2 013-0010-00 013-0010-00 - 1/2-13 Mechanical Lock Nut
$2.99
7 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
11 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
12 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
14 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
20 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
54 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
60 018-2055-00 018-2055-00 - 10mm Damper Stud-XP Linkage
$2.99
64 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
65 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
80 018-8063-00 018-8063-00 - 5/16-18 X 3/4 Hex Bolt
$2.99
86 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
87 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
89 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
93 019-8027-00 019-8027-00 -.515 ID Plastic Shoulder Washer
$2.99
97 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
127 031-0017-01 031-0017-01 - Left Steering Arm Assembly (See Models Used On for Details)
$145.99
129 031-0018-01 031-0018-01 - Right Steering Arm Assembly (See Models Used On for Details)
$145.99
141 034-8025-00 034-8025-00 - Drive Lever Housing Spring
$4.07
144 035-5450-00 035-5450-00 - Right Steering Push Rod (See Models Used On For Details)
$33.95
145 035-5451-00 035-5451-00 - Left Steering Push Rod (See Models Used On For Details)
$42.58
194 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
202 087-0001-00 087-0001-00 - Steering Damper (See Models Used On For Details)
$62.40
202 087-0010-00 087-0010-00 - Bagger Gas Shock
$106.99
