2023 ZT Elite - Fuel Tank, Seat & Console Detail

2023 ZT Elite - Fuel Tank, Seat & Console Detail

The fuel tank, seat, and console are crucial elements for both comfort and functionality on your 2023 ZT Elite. At BadBoyMowerParts.com, we offer a wide selection of Bad Boy Mower Parts to replace or upgrade these components. Whether you're looking to replace a damaged fuel tank, upgrade your seat for added comfort, or ensure the console is functioning properly, we have the parts you need. Our detailed Bad Boy Mower Part diagrams will help you easily identify the right parts for your mower. We provide only high-quality Bad Boy Lawn Mower Parts, ensuring long-lasting performance. Shopping Bad Boy Parts Online is convenient, and with Free Shipping On Orders Over $100, you’ll save on every order. Enhance the functionality and comfort of your 2023 ZT Elite with parts from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2023 ZT Elite - Fuel Tank, Seat & Console Detail
  Position Number SKU Product Title Price
44.0 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
44.1 017-9077-00 017-9077-00 - Pillow Block-Male
$21.28
44.2 017-9079-00 017-9079-00 - Pillow Block-Metal Plate
$21.28
111.0 026-0019-01 026-0019-01 - Foot Pedal Assembly (See Models Used On For Details)
$93.69
111.1 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
111.2 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
111.3 026-0019-00 026-0019-00 - Shallow Foot Pedal (See Models Used On For Detail)
$31.22
111.4 031-0500-00 031-0500-00 - 2017-2024 Deck Pedal Lever (See Models Used On For Detail)
$31.22
120.0 028-0070-17 028-0070-17 - Deck Height Bar Assy. (See Models Used On for Details)
$29.66
120.1 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
120.2 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
120.3 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
120.4 026-1100-00 026-1100-00 - 2017-Newer CAM Plate Use With Deck Adjuster (See Models Used On For Detail)
$15.55
120.5 028-0014-00 028-0014-00 - Deck Height Dial Rod (See Models Used For Detail)
$31.17
142.0 034-8045-03 034-8045-03 - Seat Spring Assembly (See Models Used On For Detail)
$32.09
142.1 013-0017-00 013-0017-00 - 3/8-16 Half Jam Nut
$2.99
142.2 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
142.3 018-3000-00 018-3000-00 - 3/8-16 X 2 Hex Bolts Zinc
$2.99
142.5 034-8045-00 034-8045-00 - Seat Spring
$20.49
143.0 034-8045-22 034-8045-22 - 2022 Mav/HD seat spring assembly with st
$32.09
143.6 064-8083-00 064-8083-00 Seat Strap w/Buckles
$24.60
165.1 051-8067-00 051-8067-00 - 1/4 Fuel Line Hose (Priced by the Foot)
$6.41
165.2 072-8069-00 072-8069-00 - 1/4 Fuel Line Clamp
$2.99
165.4 067-6057-00 067-6057-00 2 Way Fuel Shut-Off Valve
$16.04
166.2 051-2014-01 051-2014-01 - 37" 1/4 Fuel Line (No Clamp)
$19.25
185.0 067-2021-00 067-2021-00 - 2021-2024 Maverick Left Side Tank
$349.99
185.1 066-8083-00 066-8083-00 - 3.5" Tethered Fuel Cap
$23.53
185.2 067-0011-00 067-0011-00 - Fuel Line Pickup Tube
$23.41
185.3 067-4090-00 067-4090-00 - Fuel Gauge (See Models Used On For Details)
$46.00
185.4 067-6070-00 067-6070-00 - Rollover Valve and Grommet New
$24.60
185.5 067-6080-00 067-6080-00 - Grommet for ZT Elite Fuel Line Pickup Tube
$8.01
187.0 069-1051-21 069-1051-21 - Load Balanced Brake Handle Assembly
$70.97
187.1 013-0012-00 013-0012-00 - 3/8-16 Centerlock Half Nut
$3.29
187.2 013-8042-00 013-8042-00 - 5/16-18 Nylon Insert Cap Locknut Zinc (Black Cap)
$2.99
187.4 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
187.5 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
187.8 025-0001-00 025-0001-00 - Brake Lever Spacer (See Models Used On For Detail)
$8.01
187.9 032-5053-00 032-5053-00 - Bronze Bushing SF-1220-8 2013 & UP CZT/ZT Brake Bushing
$2.99
187.10 039-0170-00 039-0170-00 - Brake Cable Extension Plate
$10.99
187.11 039-0171-00 039-0171-00 - Brake Load Balancer Weldment
$10.99
187.12 069-1051-00 069-1051-00 - Load Balanced Brake Handle With Grip
$64.19
192.0 071-2101-00 071-2101-00 - 2021-2024 ZT Elite Seat
$625.99
192.1 039-2157-00 039-2157-00 - Black Seat stop
$14.19
192.3 071-2054-00 071-2054-00 - Arm Rest Kit (See Models Used On For Details) (obsolete)
use part #071-2119-00
$139.99
192.4 071-2101-02 071-2101-02 - Back Cover for 071-2101-00
$96.29
192.5 071-2102-02 071-2102-02 - Seat Cover (See Models Used On For Details)
$131.37
192.6 071-5015-00 071-5015-00 - Seat Rails
$93.69
192.7 071-8061-00 071-8061-00 - Seat Switch (See Models Used On For Detail)
$19.14
198.1 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
198.2 018-1040-00 018-1040-00 - Light Plug
$2.99
198.3 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
198.5 056-8058-00 056-8058-00 - PTO Engager-Switch for Blades
$34.29
198.6 077-8076-00 077-8076-00 - 3-Position Ignition Switch (key not included)
$21.39
198.7 079-3461-00 079-3461-00 - Control Panel--Orange
$23.53
198.8 083-4013-00 083-4013-00 - Tachometer-N211-0100-1003
$74.89
198.9 091-4072-00 091-4072-00 - Control Panel Decal
$9.89
201.1 086-1202-01 086-1202-01 - 2019-2024 Relay Cap Kit
$18.45
201.2 086-1202-19 086-1202-19 - Relay Terminal
$24.97
201 086-3050-19 086-3050-19 - 2019-2023 MZ/ZT/Maverick/Compact Outlaw Wiring Harness (obsolete)
use part #086-3600-00
$299.99
