2024 Maverick - Seat, Brake & Console - Detail

2024 Maverick - Seat, Brake & Console - Detail

The 2024 Maverick Seat, Brake & Console - Detail section includes vital components that ensure safety, comfort, and control. At BadBoyMowerParts.com, we provide top-quality Bad Boy Mower Parts designed to keep these systems functioning properly. Whether you need seat cushions, brake components, or console panels, our Bad Boy Mower Part Diagrams help you find the exact parts required for your 2024 Maverick. Our extensive inventory of Bad Boy Lawn Mower Parts guarantees that you’ll receive high-quality replacements that fit perfectly. Shopping for Bad Boy Parts Online is easy, ensuring you get the parts you need without delay. Plus, take advantage of Free Shipping On Orders Over $100, making maintenance and repairs more affordable. Keep your seat, brake, and console in peak condition by ordering from BadBoyMowerParts.com today.

Bad Boy Mower Parts Lookup

2024 Maverick - Seat, Brake & Console - Detail
  Position Number SKU Product Title Price
1.0 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
1 017-9077-00 017-9077-00 - Pillow Block-Male
$21.28
2 017-9079-00 017-9079-00 - Pillow Block-Metal Plate
$21.28
3.0 026-0019-01 026-0019-01 - Foot Pedal Assembly (See Models Used On For Details)
$93.69
3 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
4 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
5 026-0019-00 026-0019-00 - Shallow Foot Pedal (See Models Used On For Detail)
$31.22
6 031-0500-00 031-0500-00 - 2017-2024 Deck Pedal Lever (See Models Used On For Detail)
$31.22
7.0 028-0070-17 028-0070-17 - Deck Height Bar Assy. (See Models Used On for Details)
$29.66
7 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
8 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
9 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
10 026-1100-00 026-1100-00 - 2017-Newer CAM Plate Use With Deck Adjuster (See Models Used On For Detail)
$15.55
11 028-0014-00 028-0014-00 - Deck Height Dial Rod (See Models Used For Detail)
$31.17
12.0 034-8045-03 034-8045-03 - Seat Spring Assembly (See Models Used On For Detail)
$32.09
12.1 034-8045-22 034-8045-22 - 2022 Mav/HD seat spring assembly with st
$32.09
12 013-0017-00 013-0017-00 - 3/8-16 Half Jam Nut
$2.99
13 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
14 018-3000-00 018-3000-00 - 3/8-16 X 2 Hex Bolts Zinc
$2.99
16 034-8045-00 034-8045-00 - Seat Spring
$20.49
17 064-8083-00 064-8083-00 Seat Strap w/Buckles
$24.60
18 051-8067-00 051-8067-00 - 1/4 Fuel Line Hose (Priced by the Foot)
$6.41
19 072-8069-00 072-8069-00 - 1/4 Fuel Line Clamp
$2.99
21 067-6057-00 067-6057-00 2 Way Fuel Shut-Off Valve
$16.04
22 051-2014-01 051-2014-01 - 37" 1/4 Fuel Line (No Clamp)
$19.25
23.0 067-2021-00 067-2021-00 - 2021-2024 Maverick Left Side Tank
$349.99
23 066-8083-00 066-8083-00 - 3.5" Tethered Fuel Cap
$23.53
24 067-4090-00 067-4090-00 - Fuel Gauge (See Models Used On For Details)
$46.00
25 067-6070-00 067-6070-00 - Rollover Valve and Grommet New
$24.60
27.0 069-1051-21 069-1051-21 - Load Balanced Brake Handle Assembly
$70.97
27 013-0012-00 013-0012-00 - 3/8-16 Centerlock Half Nut
$3.29
28 013-8042-00 013-8042-00 - 5/16-18 Nylon Insert Cap Locknut Zinc (Black Cap)
$2.99
30 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
31 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
34 025-0001-00 025-0001-00 - Brake Lever Spacer (See Models Used On For Detail)
$8.01
35 032-5053-00 032-5053-00 - Bronze Bushing SF-1220-8 2013 & UP CZT/ZT Brake Bushing
$2.99
36 039-0170-00 039-0170-00 - Brake Cable Extension Plate
$10.99
37 039-0171-00 039-0171-00 - Brake Load Balancer Weldment
$10.99
38 069-1051-00 069-1051-00 - Load Balanced Brake Handle With Grip
$64.19
39.0 071-2500-00 071-2500-00 - Maverick Digital Seat
$599.99
39 071-2500-01 071-2500-01 - Back Cover 2024 Maverick Digital Seat
$106.99
40 071-2500-02 071-2500-02 - Seat Cover 2024 Maverick Digital Seat
$106.99
41 071-2500-03 071-2500-03 - Extended Pin (Poly Pad) Arms Pair 2024 M
$129.99
44 071-2500-06 071-2500-06 - Seat Belt Assembly for 2024 Maverick Dig
$119.99
45 071-8061-00 071-8061-00 - Seat Switch (See Models Used On For Detail)
$19.14
46 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
47 018-1040-00 018-1040-00 - Light Plug
$2.99
48 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
50 056-8058-00 056-8058-00 - PTO Engager-Switch for Blades
$34.29
51A 042-9000-00 042-9000-00 - Ignition Key
$4.06
51 077-8076-00 077-8076-00 - 3-Position Ignition Switch (key not included)
$21.39
52 079-3461-00 079-3461-00 - Control Panel--Orange
$23.53
53 083-4013-00 083-4013-00 - Tachometer-N211-0100-1003
$74.89
54 091-4072-00 091-4072-00 - Control Panel Decal
$9.89
55.0 086-3600-00 086-3600-00 - Wiring Harness With Clips (See Models Used On For Details)
$299.99
55 086-1202-01 086-1202-01 - 2019-2024 Relay Cap Kit
$18.45
56 086-1202-19 086-1202-19 - Relay Terminal
$24.97
