2024 Revolt (36" Deck) - Engine - Kawasaki FX691

2024 Revolt (36" Deck) - Engine - Kawasaki FX691

The 2024 Revolt (36" Deck) Engine - Kawasaki FX691 is a powerful engine choice for your mower, and keeping it in excellent condition is essential for maintaining the performance of your 2024 Revolt (36" Deck). At Bad Boy Mower Parts, we offer a variety of Bad Boy Mower Parts to keep your engine running smoothly, from replacement parts to complete engine kits. Detailed Bad Boy Mower Part Diagrams are available to help you identify specific parts for the Kawasaki FX691 engine and make replacements or repairs quickly. As a trusted source for Bad Boy Lawn Mower Parts, we carry everything you need to service your engine. When shopping for Bad Boy Parts Online, you can easily find the right components, all backed by our guarantee of Free Shipping On Orders Over $100, ensuring you get everything you need without any additional costs.

Bad Boy Mower Parts Lookup

2024 Revolt (36" Deck) - Engine - Kawasaki FX691
  Position Number SKU Product Title Price
1A 063-2000-14 063-2000-14 - Kawasaki FX691V & FX730V Engine Service Kit
$127.15
1B 063-2096-00 063-2096-00 - Oil Filter for Kawasaki FR/FS/FX691/FX730/FX751
$28.88
1B 055-8021-75 055-8021-75 - 52" Throttle Cable ONLY (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$28.88
1D 054-8017-00 054-8017-00 - 62" Choke Cable (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$25.80
1 070-1000-00 070-1000-00 - PTO Clutch (See Models Used On For Details)
$279.99
2 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
3 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley - Extended Shaft (See Models Used On For Details)
$42.58
4 019-6029-00 019-6029-00 - 1.140x1.750x.132 Flat Washer
$2.99
5 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
6 042-5020-00 042-5020-00 - 1/4 X 2 Square Key Stock
$2.99
7 018-5300-21 018-5300-21 - 7/16-20x2.5 Hex Bolt GR 8 W/ Patch
$3.73
8 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
9 015-0692-00 015-0692-00 - Exhaust-Stand On-FX691V Kawasaki
$145.95
10 064-0030-00 064-0030-00 - 24 inch Black Battery Cable
$18.72
11 051-5404-00 051-5404-00 - Kawasaki Oil Drain (See Models Used On For Details)
$42.58
13 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
14 013-0075-00 013-0075-00 - M8 - 1.25 Zinc Nut
$3.29
15 018-5321-00 018-5321-00 - M8 x 1.25 x 20MM Hex Head Bolt
$2.99
16 018-1075-00 018-1075-00 - 3/8 x 1 1/8 Engine Mounting Bolt
$2.99
17 018-5350-00 018-5350-00 - 5/16-18 X 5-1/2 Hex Bolt
$2.99
18 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
19 013-9005-00 013-9005-00 - 5/16-18 Nylock Jam Nut
$2.99
20 086-9002-19 086-9002-19 - Wiring Harness Adaptor-All Kawasaki FX (See Models Used On For Details)
$20.29
21 063-6000-00 063-6000-00 - Universal Inline Fuel Filter
$14.19
22 063-8019-00 063-8019-00 - Outer Air Filter, Fits all except 23 Briggs/Diesel
$35.84
23 063-8020-00 063-8020-00 - Inner Canister Air Filter - Fits All except 23 Briggs/Diesel
$32.65
24 015-8001-00 015-8001-00 - Spark Plug-Kawasaki (NGK or Equivalent) - Not For FX781, FX820 or FX1000
$8.79
25 015-2709-00 015-2709-00 - Exhaust Gasket (See Models Used On For Detail)
$8.01
