2024 ZT Elite - Floorboard & Front Pivots

2024 ZT Elite - Floorboard & Front Pivots

The 2024 ZT Elite Floorboard & Front Pivots are essential for maintaining your mower's stability and comfort during operation. If you're looking to replace or upgrade these parts, BadBoyMowerParts.com has everything you need. We offer a variety of Bad Boy Mower Parts that will fit your 2024 ZT Elite, ensuring your mower remains in top working condition. Our Bad Boy Mower Part diagrams make it simple to find and order the exact Bad Boy Lawn Mower Parts for your floorboard and front pivots. Whether you're performing a small repair or a full replacement, we provide quality parts and easy ordering. Shopping for Bad Boy Parts Online allows you to shop from home, and with Free Shipping On Orders Over $100, you can get your 2024 ZT Elite Floorboard & Front Pivots delivered to your door with no extra shipping costs.

Bad Boy Mower Parts Lookup

2024 ZT Elite - Floorboard & Front Pivots
  Position Number SKU Product Title Price
1.0 039-5944-01 039-5944-01 - Pump Idler Bracket Assy (See Models Used On For Details)
$62.46
1 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
3 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
4 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
5 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
6 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
7 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
8 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
9.0 067-0020-01 067-0020-01 - 2019-2025 ZT/Maverick EPA Cannister Assy, Also Fits 2019-2021 Compact Outlaw
$85.59
9 051-2020-01 051-2020-01 - 1/4 Vinyl 46" EPA Line (See Models Used On For Details)
$12.48
10 051-2025-02 051-2025-02 - 3/16 Vinyl 55" EPA Line
$12.48
11 067-0020-00 067-0020-00 - Carbon Canister
$62.40
12 072-8070-00 072-8070-00 - Tank Hose Clamp 3/16 (See Models Used On For Detail)
$2.99
13 072-8073-00 072-8073-00 - 3/16" Vinyl Hose Clamp
$2.99
14.0 079-3470-21 079-3470-21 - 2021 Maverick Floorboard Assembly
$159.99
14 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
15 079-3470-18 079-3470-18 - Floor Panel 2018-2024 Maverick, 2021-2024 ZT Elite
$106.99
16 081-4001-00 081-4001-00 - 2021-2024 Floor Mat W/ Reaper Tread
$53.49
17.0 250-1801-21 250-1801-21 - 2021-2022 ZT Suspension Arm Assembly Left
$106.99
17.1 250-1751-21 250-1751-21 2021-2024 ZT Suspension Arm Assy. Short Right
$109.99
17.2 250-1851-21 250-1851-21 - 2021-2022 ZT Suspension Arm Assembly Long Right (54 & 60 Decks)
$106.99
17 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
18 014-3010-00 014-3010-00 - 5/8 Round Insert
$2.99
19 025-0003-00 025-0003-00 - Front Bearing Spacer
$14.04
21 250-1801-00 250-1801-00 - 2021-2022 ZT Suspension Component Left
$80.24
