2025 Maverick - Engine - Kohler ZT740

2025 Maverick - Engine - Kohler ZT740

The Kohler ZT740 engine is known for its durability and power, but like any engine, it requires proper maintenance. At BadBoyMowerParts.com, we stock a full range of Bad Boy Mower parts to keep your 2025 Maverick running smoothly. Whether you need new spark plugs, fuel filters, or valve components, our Bad Boy Mower part diagrams for 2025 Maverick make it simple to find the right part. Keeping up with engine maintenance ensures optimal performance, fuel efficiency, and a longer lifespan for your mower. We carry fast-moving parts so you can get what you need quickly, and we offer Free Shipping On Orders Over $100 for added savings. Don’t wait until your Kohler engine starts showing signs of wear—order today and keep your Maverick in top condition with quality replacement parts from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2025 Maverick - Engine - Kohler ZT740
  Position Number SKU Product Title Price
1A 063-2000-07 063-2000-07 - Kohler Confidant (ZT740) Engine Service Kit
$102.57
1 013-8240-00 013-8240-00 - M8 Nut For Exhaust (See Models Used On For Details)
$7.36
2A 055-8020-00 055-8020-00 - Throttle Cable-53" (See Models Used On For Details)
$38.97
2B 054-8017-00 054-8017-00 - 62" Choke Cable (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$25.80
2 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
3 015-0051-00 015-0051-00 - 2017-2024 Kohler Exhaust MZ/ZT/Maverick
$217.48
4A 063-5005-00 063-5005-00 - Air Filter for Kohler ZT740
$50.28
4B 063-5006-00 063-5006-00 - Kohler ZT740 Precleaner
$9.47
4C 063-5004-00 063-5004-00 - Oil Filter for Kohler KT725, KT740, KT745, ZT740, CV749 & ECV749 Engines
$29.69
4D 063-6000-00 063-6000-00 - Universal Inline Fuel Filter
$14.19
4E 015-9080-00 015-9080-00 - Air Cleaner Cover - Kohler Confidant Only
$85.59
4 015-2030-00 015-2030-00 - 25hp Kohler- ZT740-3048
$2799.00
5 015-2751-00 015-2751-00 - Exhaust Gasket for 27,30 hp Kohler Engines
$6.56
6 015-8000-00 015-8000-00 - Spark Plug (RC12YC or Equivalent)
$13.90
7 018-1075-00 018-1075-00 - 3/8 x 1 1/8 Engine Mounting Bolt
$2.99
8 018-5300-21 018-5300-21 - 7/16-20x2.5 Hex Bolt GR 8 W/ Patch
$3.73
9 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
10 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
11 019-6029-00 019-6029-00 - 1.140x1.750x.132 Flat Washer
$2.99
12 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
13 030-7044-00 030-7044-00 - 5/16-18 x HWH unslot (F) tcs zinc
$2.99
14 032-6000-00 032-6000-00 - Cut 12" Heat Sleeve
$2.99
15 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley - Extended Shaft (See Models Used On For Details)
$42.58
16 041-7400-00 041-7400-00 - Pump Belt for Maverick and Maverick HD
$64.19
17 042-5020-00 042-5020-00 - 1/4 X 2 Square Key Stock
$2.99
18 043-8930-98 043-8930-98 - 2023-2024 Battery Hold Down Assembly Strap
$26.74
19 051-5401-00 051-5401-00 - Kohler/Briggs Oil Drain Hose
$31.17
20 064-0030-00 064-0030-00 - 24 inch Black Battery Cable
$18.72
21 064-5300-00 064-5300-00 - 24" Red Battery Cable
$21.85
22 064-5301-00 064-5301-00 - 12" Red Battery Cable
$17.16
27 108-0001-00 108-0001-00 - Solenoid
$29.41
29 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
34 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
36 018-6049-00 018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc
$2.99
39 039-0267-00 039-0267-00-ZT Clutch Bracket-Plated
$21.39
40 070-0059-00 070-0059-00 - 120 Ft Lb. Clutch- 1 1/8 Shaft
$359.99
41 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
42 018-5350-00 018-5350-00 - 5/16-18 X 5-1/2 Hex Bolt
$2.99
43 018-5450-21 018-5450-21 - 7/16-20 x 1.5" Hex bolt GR 8 w/ Patch
$2.99
44 019-0010-00 019-0010-00 - 7/16 x 1-5/8 OD x 1/4 Thick Custom AISI 1018 CF ZC
$5.93
45 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
46 070-0056-00 070-0056-00 - PTO Clutch (See Models Used On For Details)
$364.84
