2025 Rebel & Rebel X - Engine - Vanguard EFI

2025 Rebel & Rebel X - Engine - Vanguard EFI

The 2025 Rebel & Rebel X Engine - Vanguard EFI offers a combination of power and efficiency, but maintaining it with Bad Boy Mower Parts is key to longevity. At BadBoyMowerParts.com, we supply high-quality Bad Boy Lawn Mower Parts, including fuel injectors, ignition modules, air filters, and sensors to ensure optimal EFI performance. Our Bad Boy Mower Part diagrams make it easy to locate and order the necessary parts for quick repairs. Keeping your EFI engine in peak condition improves fuel economy, enhances power delivery, and extends engine life. We offer Bad Boy Parts Online for fast and reliable ordering, reducing downtime and keeping your mower running smoothly. Plus, with Free Shipping On Orders Over $100, maintaining your engine is more cost-effective than ever. Ensure your 2025 Rebel & Rebel X Engine - Vanguard EFI operates at full power—order replacement parts today for superior performance.

Bad Boy Mower Parts Lookup

2025 Rebel & Rebel X - Engine - Vanguard EFI
  Position Number SKU Product Title Price
1A 063-2000-22 063-2000-22 - Engine Service Kit - Briggs Vanguard 810/993/999cc (EFI Models Only)
$127.15
1 013-0009-00 013-0009-00 - 3/8-16 Hex Flange Top Lock Nut
$2.99
2A 055-8021-75 055-8021-75 - 52" Throttle Cable ONLY (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$28.88
2 013-0075-00 013-0075-00 - M8 - 1.25 Zinc Nut
$3.29
3 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
4 015-0025-00 015-0025-00 - Exhaust Gasket for Vanguard (obsolete)
use part #015-2708-00
$16.04
5 015-0050-01 015-0050-01 - O2 Bung Plug 12mm x 1.25
$9.89
6 015-1014-00 015-1014-00 - Exhaust (See Models Used On For Details)
$199.00
7 015-3001-00 015-3001-00 - Vanguard EFI 37HP 993cc Vertical Shaft (See Models Used On For Details)
$3499.99
8 015-8000-03 015-8000-03 - Spark Plug for Vanguard 37hp EFI and 28hp EFI (Not for Non-EFI)
$7.69
10 018-5044-00 018-5044-00 - 3/8 x 1 Carriage Bolt
$2.99
11 018-5300-21 018-5300-21 - 7/16-20x2.5 Hex Bolt GR 8 W/ Patch
$3.73
12 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
13 019-6029-00 019-6029-00 - 1.140x1.750x.132 Flat Washer
$2.99
14 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
15 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley - Extended Shaft (See Models Used On For Details)
$42.58
17 041-8050-00 041-8050-00 - Pump Belt (See Models Used On For Detail)
$80.24
19 051-5402-00 051-5402-00 - 14mm Oil Drain Hose-36hp Vanguard
$31.22
20 063-6000-00 063-6000-00 - Universal Inline Fuel Filter
$14.19
21 063-8018-00 063-8018-00 - Oil Filter
$21.39
22 063-8019-00 063-8019-00 - Outer Air Filter, Fits all except 23 Briggs/Diesel
$35.84
23 063-8020-00 063-8020-00 - Inner Canister Air Filter - Fits All except 23 Briggs/Diesel
$32.65
24 064-5301-01 064-5301-01 - 12" Red Battery Cable for Rebel/Rebel X
$12.94
25 070-1000-00 070-1000-00 - PTO Clutch (See Models Used On For Details)
$279.99
26 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
27 070-2304-00 070-2304-00 - 2023-Newer Rebel Frame--Orange
$1099.99
28 086-0005-00 086-0005-00 - Cable - Starter to Chassis (See Models Used On For Details)
$10.21
