2025 Renegade - Diesel - Drive Arms

2025 Renegade - Diesel - Drive Arms

The 2025 Renegade - Diesel Drive Arms ensure precise handling and maneuverability, making maintenance essential for optimal mower performance. At BadBoyMowerParts.com, we provide high-quality Bad Boy Mower Parts to keep your drive arms functioning smoothly. Our Bad Boy Lawn Mower Parts selection includes drive arm assemblies, bushings, brackets, and control linkages for durability and reliability. Using our Bad Boy Mower Part diagrams, you can quickly find and order the exact drive arm components needed for repairs. A damaged or misaligned drive arm can cause steering issues, reducing efficiency and increasing wear on other mower parts. We stock Bad Boy Parts Online for quick replacements and fast shipping. Plus, enjoy Free Shipping On Orders Over $100, making repairs both convenient and budget-friendly. Keep your 2025 Renegade - Diesel Drive Arms in peak condition—order today for smooth, effortless control and superior mowing performance.

Bad Boy Mower Parts Lookup

2025 Renegade - Diesel - Drive Arms
  Position Number SKU Product Title Price
1 013-0021-00 013-0021-00 - Extruded Nut 3/8"-16 3/4"
$4.39
2 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
3 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc
$2.99
4 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
5 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
6 018-0078-00 018-0078-00 - 3/8"-16 Thread Size, 1" 1/4 Long
$2.99
7 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
8 018-2006-00 018-2006-00 - 5/16-18 X 1-1/4 Hex Bolt
$2.99
9 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
10 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
11 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
12 028-0051-00 028-0051-00 - Steering Actuator Rod 2019-2025 Rebel, Renegade & Rogue
$23.41
13 031-0030-24 031-0030-24 - 2024 R Series RH Arm Rod Assembly
$96.29
14 031-0031-24 031-0031-24 - 2024 R Series LH Arm Rod Assembly
$96.29
15 031-9070-00 031-9070-00 - R-Series Square Drive Arm RH Assembly
$129.99
16 031-9071-00 031-9071-00 - R-Series Square Drive Arm LH Assembly
$129.99
17 032-0002-00 032-0002-00 - Snap-In Bushing 2019-2022 Rebel, Renegade & Rogue
$15.55
18 035-0005-00 035-0005-00 - Push Rod Assembly 2019-2025 Renegade
$46.84
20 057-5800-00 057-5800-00 - Speed Limiting Knob 3/8-16X 3"
$6.41
22 077-8075-00 077-8075-00 - Rail Mount Safety Switch
$6.59
23 087-0002-00 087-0002-00 - Steering Rod Damper With Spherical Rod Ends For Renegade/Rogue (See Models Used On For Details)
$62.46
24 091-1114-00 091-1114-00 - 2018-2022 LH/RH Steering Control Decal Roll
$15.60
