Click Image to Change Diagram
The 2025 Renegade - Diesel Fuel Line Assembly is essential for delivering a steady and clean fuel supply to your mower’s engine. At BadBoyMowerParts.com, we provide premium Bad Boy Mower Parts to keep your fuel system running efficiently. Our Bad Boy Lawn Mower Parts selection includes fuel hoses, clamps, connectors, and inline filters for leak-free operation. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct fuel line components for fast replacements. A clogged or damaged fuel line can lead to engine misfires and reduced efficiency, making maintenance essential. We stock Bad Boy Parts Online for easy ordering and quick delivery. Plus, with Free Shipping On Orders Over $100, maintaining your fuel system is both affordable and hassle-free. Keep your 2025 Renegade - Diesel Fuel Line Assembly functioning properly—order today for reliable fuel delivery and peak engine performance.
![]() |
Position Number | SKU | Product Title | Price | ||
---|---|---|---|---|---|
1 | 051-8067-00 | 051-8067-00 - 1/4 Fuel Line Hose (Priced by the Foot) |
$6.41
|
||
2 | 051-8068-00 | 051-8068-00 - 3/16 Fuel Line |
$3.59
|
||
3 | 051-8069-00 | 051-8069-00 - 5/16 Clear Hose (Priced Per Foot) |
$2.99
|
||
4 | 051-8075-00 | 051-8075-00 - 5/16 Fuel Line Hose Priced per Foot |
$7.69
|
||
5 | 072-8068-00 | 072-8068-00 - 5/16 Fuel Line Clamp |
$3.62
|
||
6 | 072-8069-00 | 072-8069-00 - 1/4 Fuel Line Clamp |
$2.99
|
||
7 | 072-8070-00 | 072-8070-00 - Tank Hose Clamp 3/16 (See Models Used On For Detail) |
$2.99
|
||
8 | 073-2000-00 | 073-2000-00 - Brass Fuel Line T - Diesels |
$10.21
|
