2025 Renegade - Gas - 72" Deck Assembly

2025 Renegade - Gas - 72" Deck Assembly

The 2025 Renegade - Gas 72" Deck Assembly is built for maximum efficiency and precision, making routine maintenance essential. At BadBoyMowerParts.com, we offer high-performance Bad Boy Mower Parts to keep your cutting deck running smoothly. Our Bad Boy Lawn Mower Parts inventory includes heavy-duty blades, deck spindles, pulleys, and belts for superior mowing performance. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the exact parts needed for seamless repairs. A properly maintained deck reduces vibrations, improves cutting consistency, and ensures longer-lasting components. We keep Bad Boy Parts Online available for immediate shipping, minimizing downtime and maximizing productivity. Plus, with Free Shipping On Orders Over $100, maintaining your 2025 Renegade - Gas 72" Deck Assembly is now more budget-friendly. Order today and keep your mower cutting at peak efficiency.

Bad Boy Mower Parts Lookup

2025 Renegade - Gas - 72" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1B 210-0372-00 210-0372-00 - 2019-2025 72" Mulch Kit w/Blades Outlaws
$318.45
1C 092-4010-23 092-4010-23 Top Discharge Bagger (2019-2025 72" Renegade)
$2799.99
1 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
2 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
3 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
4 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
5 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
6 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
9 018-0046-00 018-0046-00 - 1/2-13 x 8" Hex Bolt
$4.06
10 018-0075-00 018-0075-00 - 3/8-16 x 1-3/4 Hex C/S () ZC
$3.29
11 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
12 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
13 018-4700-00 018-4700-00 - 3/8-16 X 3 Hex Bolts Zinc
$2.99
14 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
15 018-4707-00 018-4707-00 - 4" 3/8-16 Eye Bolt
$4.06
16 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
17 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
18 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
19 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
20 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
21 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 Hex Bolts
$2.99
22 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
23 018-8066-00 018-8066-00 - 5/16 x 7/8 Carriage Bolt
$2.99
24 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
25 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
26 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
27 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
28 022-1001-00 022-1001-00 - Deck Wheel (See Models Used On For Detail)
$17.11
29 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
30 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
31 025-7020-00 025-7020-00 - 5/8 Set Collar w/One Set Screw
$4.37
32 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
33 026-0234-00 026-0234-00 - 61" Bolt In Baffle Deck V2 Striping Plat
$172.99
34 029-7036-00 029-7036-00 - Deck Trim Bumper
$23.41
35 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
36 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
37 033-7203-00 033-7203-00 - 7" Spindle Deck Pulley 72" Decks
$35.48
38 034-2030-00 034-2030-00 - 2019-Newer Deck Spring (See Models Used On For Details)
$31.22
39 037-4000-00 037-4000-00 - Commercial Spindle Assembly (See Models Used On For Details)
$291.91
40.1 038-5400-00 038-5400-00 - 72" Gator Mulching Blade
$24.99
40 038-7230-00 038-7230-00 - 72" High Lift Fusion Blade
$24.99
41 039-0144-00 039-0144-00 - Deck Eye Bolt Tab For Rebel/Renegade/Rogue (See Models Used On For Details)
$14.19
42 039-2125-17 039-2125-17 - Deck Hanger Assembly (See Models Used On For Details)
$15.60
43 039-6946-17 039-6946-17 - 2019-2025 Renegade Deck Idler Assembly
$78.08
44 041-2375-00 041-2375-00 - B237.50 Deck Belt for 60" AOS Diesel & 72" AOS Gas Models (NOT FOR 72" DIESEL)
$131.30
45 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
46 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
47 048-8000-00 048-8000-00 Turnbuckle Assembly (obsolete)
use part #048-9000-00
$80.24
48 060-7251-19 060-7251-19 - 72" Sloped Deck Shell 2019-Newer Rebel, Renegade & Rogue
$1461.53
49 084-5004-00 084-5004-00 - R Series Rubber for Deck
$56.77
51 091-3012-00 091-3012-00 - Danger Decal-Spindle/Discharge
$2.99
52 091-4033-00 091-4033-00 - 2019-2022 Renegade Deck Belt Route Decal
$9.61
53 091-8001-00 091-8001-00 - Impact Absorption Patent Decal
$2.99
54 099-7000-00 099-7000-00 - Deck Step Assembly (See Models Used On For Details)
$53.49
55 210-7000-98 210-7000-98 - Chute Assembly (See Models Used On for Detail)
$159.22
