2025 Renegade - Gas - Fuel Tanks & Console

2025 Renegade - Gas - Fuel Tanks & Console

The 2025 Renegade - Gas Fuel Tanks & Console system is essential for efficient fuel storage and user-friendly mower operation. At BadBoyMowerParts.com, we offer high-quality Bad Boy Mower Parts to maintain your mower’s fuel system and control panel. Our Bad Boy Lawn Mower Parts inventory includes fuel tanks, gauges, console covers, and electrical components for long-lasting reliability. With our Bad Boy Mower Part diagrams, you can easily locate and order the correct replacement parts for fast repairs. A properly maintained fuel tank prevents leaks, while a functional console improves mower control and accessibility. We stock Bad Boy Parts Online to provide quick replacements, reducing downtime. Plus, with Free Shipping On Orders Over $100, keeping your 2025 Renegade - Gas Fuel Tanks & Console system in top shape is more affordable than ever. Order today for secure fuel storage and enhanced mower functionality.

Bad Boy Mower Parts Lookup

2025 Renegade - Gas - Fuel Tanks & Console
  Position Number SKU Product Title Price
1 015-9990-03 015-9990-03 - Fuel Pump Kit for 015-9990-00/015-9991-00
$569.99
2 018-0068-00 018-0068-00 - 5/16-18 x 5/8 Hex Bolt
$3.29
3 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
4 018-2010-00 018-2010-00 - 10-32 X 3/8 BS C/S 18-8 SS
$2.99
5 018-2012-00 018-2012-00 - 1/4-20 X 1/2 BS C/S 18-8 SS
$2.99
6 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
7 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
8 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
9 030-7041-00 030-7041-00 - 1/4-20x1/2 HWH Bolt Slot Type
$2.99
12 067-8053-18 067-8053-18 - LH Renegade Hydro Tank Assy
$201.96
13 067-8054-18 067-8054-18 - RH Renegade Hydro Tank Assy
$201.96
14 067-9950-50 067-9950-50 - Rebel/Rogue/Renegade Right Fuel Tank
$341.99
15 067-9960-50 067-9960-50 - Rebel/Rogue/Renegade Left Fuel Tank
$262.99
16 070-5373-19 070-5373-19 - 2019-2022 Horizontal Gas Frame Welded Assembly
$1461.53
17 072-8076-00 072-8076-00 - 12.5mm/15mm OETIKER 2 Ear Clamp
$2.99
18 077-9001-00 077-9001-00 - Deck Height Dial Knob 2 to 6 2019-2022 Renegade & Rogue
$21.39
19 079-3290-00 079-3290-00 - Right Fuel Tank Insert 2019-& Up Rebel, Renegade, & Rogue
$8.79
20 079-3291-00 079-3291-00 - Renegade/Rogue/Rebel Left Fuel Tank Insert
$8.79
21 079-3482-19 079-3482-19 - Renegade Control Panel ASSY
$309.99
22 086-0012-00 086-0012-00 - 2019-2025 LCD Panel Harness
$329.99
23 091-1020-00 091-1020-00 - Hydraulic Decal (See Models Used On For Details)
$2.99
24 091-6022-00 091-6022-00 R-Series Shut Off Valve Decal
$2.99
