2025 Revolt (36" Deck) - Front End

2025 Revolt (36" Deck) - Front End

The 2025 Revolt (36" Deck) Front End is responsible for steering and stability, making regular maintenance essential. At BadBoyMowerParts.com, we stock high-quality Bad Boy Mower Parts to ensure precise handling and durability. Our Bad Boy Lawn Mower Parts inventory includes front axles, caster wheels, bushings, and mounting brackets for smooth operation. Using our Bad Boy Mower Part diagrams, you can easily identify and order the necessary front-end components for quick repairs. A properly maintained front end ensures smooth turns, reduces vibration, and improves mower performance. We provide Bad Boy Parts Online for fast shipping and convenient ordering. Plus, with Free Shipping On Orders Over $100, keeping your 2025 Revolt (36" Deck) Front End in excellent condition is now more budget-friendly. Order today to ensure superior control and maneuverability while mowing.

Bad Boy Mower Parts Lookup

2025 Revolt (36" Deck) - Front End
  Position Number SKU Product Title Price
1 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
2 029-7040-00 029-7040-00 - EZT Front Bumper (See Models Used On For Detail)
$31.17
3 026-0085-00 026-0085-00 - Exhaust Backer Plate
$16.04
4 026-0084-00 026-0084-00 - Exhaust Shield Plate 2019-2022 Revolt
$13.90
5 026-0049-00 026-0049-00 - 2019-2022 Revolt Front Bumper Plate
$26.74
6 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
7 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
8 018-0072-00 018-0072-00 - 3/8-16 x 3 Carriage Bolt Zinc GR5
$2.99
9 018-0058-00 018-0058-00 - 1/4"-20 x 3/4 Black Oxide 18-8 Stainless Pan Head No Longer Available
Obsolete.
10 018-0044-00 018-0044-00 - 3/8 x 2 1/2 Carriage Bolt
$2.99
11 018-0040-00 018-0040-00 - 1/2-13 x 8 1/2 Gr5 Hex Bolt
$7.18
12 018-0005-00 018-0005-00 - 1-14 X 5 BOLT GR 8 Zinc
$7.69
13 014-2025-00 014-2025-00 - Caster Bearing Cover (See Models Used On For Details)
$2.99
14 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
15 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
16 013-0026-00 013-0026-00 - 3/16" Diameter, for 0.1260"-0.25" Material
$3.29
17 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
19 022-3088-00 022-3088-00 - 13x6.50-6 Black No Flat Assy 2015-2019 Outlaw, 2022 - 2025 Maverick, Maverick HD, Rebel (Will Not Work On Renegade & Rogue)
$145.99
20 023-1010-00 023-1010-00 - Front Fork 2019-2022 Revolt, 2021-2022 Maverick
$145.95
21 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
22 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
23 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
