2025 Revolt (48"-61" Decks) - 54" Deck Assembly

2025 Revolt (48"-61" Decks) - 54" Deck Assembly

The 2025 Revolt (48"-61" Decks) 54" Deck Assembly provides powerful cutting capability for tackling large areas efficiently. At BadBoyMowerParts.com, we stock premium Bad Boy Mower Parts, including deck spindles, cutting blades, tensioner pulleys, and belts for superior performance. Our Bad Boy Lawn Mower Parts inventory ensures that your mower stays in top shape for smooth, consistent mowing. Using our Bad Boy Mower Part diagrams, you can quickly find and order the necessary deck components for fast replacements. A properly maintained deck assembly improves efficiency, extends mower longevity, and delivers professional-level results. We stock Bad Boy Parts Online for immediate ordering and quick shipping. Plus, with Free Shipping On Orders Over $100, maintaining your 2025 Revolt (48"-61" Decks) 54" Deck Assembly is now easier and more cost-effective. Order today and keep your deck in peak condition for flawless mowing.

Bad Boy Mower Parts Lookup

2025 Revolt (48"-61" Decks) - 54" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6048-00 088-6048-00 - Advanced Chute System for Revolt 48", 54", and 61" Decks
$249.00
1B 210-0354-00 210-0354-00 - 54" Mulch Kit w/Blades (Not for MZ or Avenger) (See Models Used On for Detail)
$318.45
1 210-7000-98 210-7000-98 - Chute Assembly (See Models Used On for Detail)
$159.22
2 039-6945-19 039-6945-19 - Revolt Deck Idler Assembly
$70.97
3 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
4 039-0245-00 039-0245-00 - 48"/54" Rear Deck Hanger--Black
$21.39
5 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
6 022-1001-00 022-1001-00 - Deck Wheel (See Models Used On For Detail)
$17.11
7 029-7036-00 029-7036-00 - Deck Trim Bumper
$23.41
8 025-0025-00 025-0025-00 - Round Spacer (See Models Used On For Details)
$7.28
9 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
10.1 038-0003-00 038-0003-00 - 54" & 2024 Raider 36" Deck Gator Mulching Blade
$22.99
10 038-0001-00 038-0001-00 - 54" & 2024 Raider 36" High Lift Fusion Blade
$22.99
11 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
12 034-2030-00 034-2030-00 - 2019-Newer Deck Spring (See Models Used On For Details)
$31.22
15 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
16 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
17 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
18 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
19 025-0032-00 025-0032-00 - Stationary Idler Spacer (See Models Used On For Details)
$8.46
20 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
21 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
22 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
23 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 Hex Bolts
$2.99
24 018-7049-00 018-7049-00 - 1/2 -13 x 4.25 gr. 5 hex bolt
$2.99
25 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
26 018-0046-00 018-0046-00 - 1/2-13 x 8" Hex Bolt
$4.06
27 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
28 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
29 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
30 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
31 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
32 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
33 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
34 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
35 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
36 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
37 018-7060-00 018-7060-00 - 3/8-16 x 5 1/2 Hex Bolt -
$2.99
38 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
39 041-0120-00 041-0120-00 - Deck Belt (See Models Used On For More Details - Not for 54" MZ)
$88.80
40 091-3012-00 091-3012-00 - Danger Decal-Spindle/Discharge
$2.99
41 091-4019-00 091-4019-00 - 2019-2022 Revolt Deck Belt Route Decal
$6.04
42 091-8001-00 091-8001-00 - Impact Absorption Patent Decal
$2.99
43 084-5005-00 084-5005-00 - 2023 MZ Stripe Kit Rubber
$56.77
44 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
45 060-2327-00 060-2327-00 - 2023 54" Revolt Deck--Painted
$1399.99
46 014-4006-00 014-4006-00 - 2023 Revolt Pulley Covers
$21.39
47 039-2125-00 039-2125-00 - Outlaw Deck Hanger Bracket (See Models Used On For Details) (obsolete)
use part #039-2125-17
$15.60
48 037-4000-00 037-4000-00 - Commercial Spindle Assembly (See Models Used On For Details)
$291.91
49 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
50 026-0307-00 026-0307-00 - 2023 4' & 5' Striping Kit Plate-Painted
$10.99
51 091-0504-00 091-0504-00 - MY24 54" Deck Decal
$10.99
52 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
53 018-6037-00 018-6037-00 - 1/2-13 X 2-1/4 Hex Bolt
$2.99
54 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
