2025 Revolt (48"-61" Decks) - Fuel Tank & Frame

2025 Revolt (48"-61" Decks) - Fuel Tank & Frame

The 2025 Revolt (48"-61" Decks) Fuel Tank & Frame system is essential for fuel efficiency and structural stability. At BadBoyMowerParts.com, we stock high-quality Bad Boy Mower Parts to maintain your mower’s fuel system and frame integrity. Our Bad Boy Lawn Mower Parts inventory includes fuel tanks, caps, hoses, frame reinforcements, and mounting brackets for reliable operation. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct fuel tank and frame components for easy installation. A secure fuel tank prevents leaks, while a reinforced frame ensures structural durability and operator safety. We provide Bad Boy Parts Online for fast replacements and quick delivery. Plus, with Free Shipping On Orders Over $100, keeping your 2025 Revolt (48"-61" Decks) Fuel Tank & Frame in excellent condition is now more budget-friendly. Order today for reliable fuel storage and structural support.

Bad Boy Mower Parts Lookup

2025 Revolt (48"-61" Decks) - Fuel Tank & Frame
  Position Number SKU Product Title Price
1 070-5220-19 070-5220-19 - 2019-2022 Revolt Frame
$1149.99
2 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
3 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
4 072-0051-00 072-0051-00 - Tank Strap 13.5" (See Models Used On For Details)
$11.34
5 031-0093-00 031-0093-00 - 2019-2022 Stand On Deck Lever Lock
$24.12
6 018-0028-00 018-0028-00 - 3/8x2 1/2" Hex Bolt
$4.39
7 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
8 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
9 069-4012-00 069-4012-00 - Revolt Lift Grip (See Models Used On For Details)
$14.19
10 024-3050-00 024-3050-00 - 1/4" Drive-in Grease Fitting (See Models Used On For Details)
$2.99
11 020-1001-00 020-1001-00 - Zinc-Plated Steel Reusable Cotter Pin No Longer Available
Obsolete.
12 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
13 019-2040-00 019-2040-00 - 1/2 Flat Washer
$2.99
14 018-0038-00 018-0038-00 - 1/2-13 x 7" Carriage Bolt
$2.99
15 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
16 018-2055-00 018-2055-00 - 10mm Damper Stud-XP Linkage
$2.99
18 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
19 031-7153-00 031-7153-00 - 2023 Revolt Lift Lever--Orange
$74.85
21 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
24 025-0081-00 025-0081-00 - Stand On Spacer 2.5" With Shoulder
$14.97
25 025-5343-00 025-5343-00 - Revolt Spacer 2.5"
$11.01
26 067-0030-23 067-0030-23 - 2023 Revolt Tank 48,54,61 DECKS ONLY
$484.99
28 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
30 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
31 066-8070-00 066-8070-00 - Revolt fuel cap (See Models Used On For Details)
$32.09
32 040-4004-00 040-4004-00 - 2023 Revolt Deck Height Pin
$16.04
33 091-0025-00 091-0025-00 - Revolt Deck Height Indicator
$16.04
36 028-0048-00 028-0048-00 - Rear Actuator Bar Weldment-LH--Black
$64.19
37 051-8067-00 051-8067-00 - 1/4 Fuel Line Hose (Priced by the Foot)
$6.41
38 072-8069-00 072-8069-00 - 1/4 Fuel Line Clamp
$2.99
39 015-0200-00 015-0200-00 - USE 063-6000-00 (obsolete)
use part #063-6000-00
$14.19
40 067-6070-00 067-6070-00 - Rollover Valve and Grommet New
$24.60
54 018-0084-00 018-0084-00 - 3/8 -16 x 3 Hex bolt
$2.99
