2025 Revolt (48"-61" Decks) - Turnbuckle & Discharge Chute

2025 Revolt (48"-61" Decks) - Turnbuckle & Discharge Chute

The 2025 Revolt (48"-61" Decks) Turnbuckle & Discharge Chute system is vital for directing grass clippings and maintaining deck height adjustments. At BadBoyMowerParts.com, we provide high-quality Bad Boy Mower Parts to keep these components functioning correctly. Our Bad Boy Lawn Mower Parts selection includes adjustable turnbuckles, discharge chutes, mounting brackets, and hardware designed for durability and long-term use. Using our Bad Boy Mower Part diagrams, you can quickly find and order the correct replacement parts for fast installation. A properly working discharge chute ensures even grass dispersion, preventing clogs and improving mowing efficiency, while a well-maintained turnbuckle maintains proper deck height adjustments. We offer Bad Boy Parts Online for quick replacements and convenient ordering. Plus, with Free Shipping On Orders Over $100, maintaining your 2025 Revolt (48"-61" Decks) Turnbuckle & Discharge Chute is now more affordable. Order today for precise cutting and smooth operation.

Bad Boy Mower Parts Lookup

2025 Revolt (48"-61" Decks) - Turnbuckle & Discharge Chute
  Position Number SKU Product Title Price
1 013-0030-00 013-0030-00 - Hex Nut M20-2.5 No Longer Available
Obsolete.
2 013-0031-00 013-0031-00 - Hex Nut M20-2.5 Left Hand Thread No Longer Available
Obsolete.
3 024-0001-00 024-0001-00 - 1/4-28 Threaded Grease Fitting
$2.99
4 032-2000-00 032-2000-00 - Toplink Bushing (See Models Used On For Detail)
$4.37
5 032-2001-00 032-2001-00 - Toplink Sleeve (See Models Used On For Detail)
$4.37
6A 048-8000-00 048-8000-00 Turnbuckle Assembly
$80.24
6 048-8020-00 048-8020-00 - 2024 Turnbuckle Body (obsolete)
use part #048-8000-00
$80.24
7 048-8021-00 048-8021-00 - Turnbuckle End Right-Handed Thread (obsolete)
use part #048-8000-00
$80.24
8 048-8022-00 048-8022-00 - Turnbuckle End Left-Handed Thread (obsolete)
use part #048-8000-00
$80.24
9 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
10 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
11 018-8066-00 018-8066-00 - 5/16 x 7/8 Carriage Bolt
$2.99
12 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
13 039-4893-00 039-4893-00 - Upper Chute Bracket (See Models Used On For Details)
$46.84
14 039-4894-00 039-4894-00 - Lower Chute Bracket (See Models Used On For Details)
$43.72
15 206-6018-00 206-6018-00 - Chute Hanger 2019-2025 Rebel, Revolt, Renegade & Rogue
$9.67
16A 210-7000-98 210-7000-98 - Chute Assembly (See Models Used On for Detail)
$159.22
16 210-6025-00 210-6025-00 - Belted Chute with Logo 2019-& Up Rebel, Revolt, Renegade & Rogue
$62.40
