2025 Revolt X - 72" Deck Assembly

2025 Revolt X - 72" Deck Assembly

The 2025 Revolt X 72" Deck Assembly is built for heavy-duty performance, making maintenance crucial for durability and efficiency. At BadBoyMowerParts.com, we supply premium Bad Boy Mower Parts, including reinforced deck spindles, high-strength blades, idler pulleys, and belt kits for reliable operation. Our Bad Boy Lawn Mower Parts inventory ensures that your mower stays in peak condition for professional-grade mowing. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct deck components for hassle-free repairs. A well-maintained deck assembly ensures smooth cutting, reduces vibration, and extends mower longevity. We provide Bad Boy Parts Online for fast ordering and quick delivery. Plus, with Free Shipping On Orders Over $100, keeping your 2025 Revolt X 72" Deck Assembly in top condition is now more budget-friendly. Order today to ensure superior cutting performance with every mow.

Bad Boy Mower Parts Lookup

2025 Revolt X - 72" Deck Assembly
  Position Number SKU Product Title Price
1 210-7000-98 210-7000-98 - Chute Assembly (See Models Used On for Detail)
$159.22
2 022-1001-00 022-1001-00 - Deck Wheel (See Models Used On For Detail)
$17.11
3.1 038-5400-00 038-5400-00 - 72" Gator Mulching Blade
$24.99
3 029-7036-00 029-7036-00 - Deck Trim Bumper
$23.41
4 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
5 033-7203-00 033-7203-00 - 7" Spindle Deck Pulley 72" Decks
$35.48
6 038-7230-00 038-7230-00 - 72" High Lift Fusion Blade
$24.99
7 037-4000-00 037-4000-00 - Commercial Spindle Assembly (See Models Used On For Details)
$291.91
8 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
9 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
10 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
11 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
12 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
13 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
14 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
15 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
16 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
17 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
18 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
19 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
20 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
21 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 Hex Bolts
$2.99
22 018-0046-00 018-0046-00 - 1/2-13 x 8" Hex Bolt
$4.06
23 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
24 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
25 091-3012-00 091-3012-00 - Danger Decal-Spindle/Discharge
$2.99
26 084-5004-00 084-5004-00 - R Series Rubber for Deck
$56.77
27 026-0234-00 026-0234-00 - 61" Bolt In Baffle Deck V2 Striping Plat
$172.99
28 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
30 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
31 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
32 034-2030-00 034-2030-00 - 2019-Newer Deck Spring (See Models Used On For Details)
$31.22
33 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
34 048-8000-00 048-8000-00 Turnbuckle Assembly
$80.24
35 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
36 041-4025-00 041-4025-00 - 72" Revolt X Deck Belt
$131.30
38 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
39 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
40 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
41 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
42 018-7060-00 018-7060-00 - 3/8-16 x 5 1/2 Hex Bolt -
$2.99
43 091-4052-00 091-4052-00 - 61" Revolt Deck Belt Route Decal
$6.59
44 039-0244-00 039-0244-00 - 61" Front Deck Hanger--Black
$21.39
47 039-0245-00 039-0245-00 - 48"/54" Rear Deck Hanger--Black
$21.39
48 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
49 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
50 014-5052-00 014-5052-00 - 61" Left Deck Pulley Cover - Rebel, Renegade & Rogue
$17.86
51 014-5053-00 014-5053-00 - 61" Right Deck Pulley Cover 2019-& Up Rebel, Renegade & Rogue
$17.86
52 025-0032-00 025-0032-00 - Stationary Idler Spacer (See Models Used On For Details)
$8.46
53 025-0025-00 025-0025-00 - Round Spacer (See Models Used On For Details)
$7.28
54 018-7049-00 018-7049-00 - 1/2 -13 x 4.25 gr. 5 hex bolt
$2.99
