2025 Revolt X - Engine - Vanguard EFI

2025 Revolt X - Engine - Vanguard EFI

The 2025 Revolt X Engine - Vanguard EFI is built for high-torque performance and reliability, but regular maintenance is key to longevity. At BadBoyMowerParts.com, we provide high-quality Bad Boy Mower Parts, including fuel injectors, oil filters, air filters, and cooling system components to ensure smooth engine operation. Our Bad Boy Lawn Mower Parts inventory ensures that you receive factory-grade parts designed for durability and efficiency. Using our Bad Boy Mower Part diagrams, you can easily locate and order the necessary engine components for fast repairs. Routine maintenance helps prevent fuel system clogs, reduces emissions, and extends engine life. We stock Bad Boy Parts Online for quick replacements and convenient ordering. Plus, with Free Shipping On Orders Over $100, maintaining your 2025 Revolt X Engine - Vanguard EFI is now more cost-effective. Order today to ensure top-tier engine performance and long-lasting reliability.

Bad Boy Mower Parts Lookup

2025 Revolt X - Engine - Vanguard EFI
  Position Number SKU Product Title Price
1A 063-2000-22 063-2000-22 - Engine Service Kit - Briggs Vanguard 810/993/999cc (EFI Models Only)
$127.15
1B 015-4040-00 015-4040-00 - 40HP Vanguard Vertical Shaft
$3999.99
1 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley - Extended Shaft (See Models Used On For Details)
$42.58
2 070-1000-00 070-1000-00 - PTO Clutch (See Models Used On For Details)
$279.99
3 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
4 018-5300-21 018-5300-21 - 7/16-20x2.5 Hex Bolt GR 8 W/ Patch
$3.73
6 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
8 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
9 015-0025-00 015-0025-00 - Exhaust Gasket for Vanguard (obsolete)
use part #015-2708-00
$16.04
10 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
11 013-4023-00 013-4023-00 - 6MM Hex Nut (One Nut)
$2.99
12 018-8063-00 018-8063-00 - 5/16-18 X 3/4 Hex Bolt
$2.99
13 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
14 063-8020-00 063-8020-00 - Inner Canister Air Filter - Fits All except 23 Briggs/Diesel
$32.65
16 015-8000-00 015-8000-00 - Spark Plug (RC12YC or Equivalent)
$13.90
18 019-6029-00 019-6029-00 - 1.140x1.750x.132 Flat Washer
$2.99
21 051-5402-00 051-5402-00 - 14mm Oil Drain Hose-36hp Vanguard
$31.22
22 063-8018-00 063-8018-00 - Oil Filter
$21.39
23 216-1000-17 216-1000-17 - 2017-2024 MZ/ZT/MAV Tach Wire Assy
$7.28
24 063-8019-00 063-8019-00 - Outer Air Filter, Fits all except 23 Briggs/Diesel
$35.84
25 013-0075-00 013-0075-00 - M8 - 1.25 Zinc Nut
$3.29
