2025 Rogue - Rear Suspension

2025 Rogue - Rear Suspension

The 2025 Rogue Rear Suspension system is essential for operator comfort and smooth mowing performance, making routine maintenance crucial. At BadBoyMowerParts.com, we provide high-quality Bad Boy Mower Parts, including shock absorbers, suspension arms, bushings, and mounting brackets to ensure durability. Our Bad Boy Lawn Mower Parts inventory features factory-grade replacements designed for long-term reliability. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct rear suspension components for seamless installation. A well-maintained suspension system absorbs shocks, reduces operator fatigue, and enhances mowing stability. We stock Bad Boy Parts Online for quick replacements and convenient ordering. Plus, with Free Shipping On Orders Over $100, maintaining your 2025 Rogue Rear Suspension is now more cost-effective. Order today to ensure a smooth ride and comfortable mowing experience.

Bad Boy Mower Parts Lookup

2025 Rogue - Rear Suspension
  Position Number SKU Product Title Price
1 013-0023-00 013-0023-00 - 3/4" Course Thread Nylon Lock Nut
$7.36
2 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
3 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
4 018-0024-00 018-0024-00 - M6-1.0 X 16MM HEX BOLT
$2.99
5 018-0045-00 018-0045-00 - 3/4 x 2 1/2 Course Thread Bolt
$2.99
6 018-0049-00 018-0049-00 - 5/8-11 x 2 3/4 Hex Head Bolt
$4.39
7 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
8 018-2030-00 018-2030-00 - 1/2 x 1 Bolt
$2.99
9 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
10 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
11 018-7033-00 018-7033-00 - 1/2-20 X 1-1/2 Lug Bolts Zinc
$2.99
12 019-0009-00 019-0009-00 - 5/8" Flat Washer SAE Spec Grade 8
$2.99
13 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
14 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
15 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
16 022-4090-00 022-4090-00 - 26x12-12 Reaper Tire/Wheel Assembly
$371.99
17 025-0034-00 025-0034-00 - Rogue Pump Washer
$4.39
18 025-0071-00 025-0071-00 - Spacer 1.125 OD X .625 ID X .250 Length
$14.19
19 025-7020-00 025-7020-00 - 5/8 Set Collar w/One Set Screw
$4.37
20 032-8999-00 032-8999-00 - Vibration Mount - Blue Dot Rear Mount for Diesel Models
$64.22
21 032-9000-00 032-9000-00 - Isolator - Green Dot
$70.97
22 033-5011-00 033-5011-00 - Cast Pump Pulley - 17mm AOS/Diesel Models
$35.48
23 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
24 039-0031-19 039-0031-19 - Pump Idler Assembly For Rogue (See Models Used On For Details)
$70.97
25 039-2145-00 039-2145-00 - Suspension Gusset (See Models Used On For Details)
$14.19
26 041-8051-00 041-8051-00 - Rogue Pump Belt 68"
$80.24
27 042-5013-00 042-5013-00 - M5 X 36MM Square Machinery Key C1018 ROUNDED ENDS
$2.99
28 048-6061-00 048-6061-00 - Rear Radius Rod W/ Greaseable Heim (See Models Used On For Detail)
$58.84
29 048-6064-00 048-6064-00 - Suspension linkage (3/4 body | 5/8 Hole)
$78.08
30 067-8053-21 067-8053-21 - LH Drive Pump & Hydraulic Tank Assembly
$699.99
31 067-8054-21 067-8054-21 - RH Drive Pump & Hydraulic Tank Assembly
$699.99
34 070-2305-00 070-2305-00 - 2023-Newer Rogue Frame--Orange
$1299.99
